BSPT(R) Taps
BSPT(R) Taps

BSPT(R) Taps

Descriptions

Type of Thread
British standard pipe (taper)
Tap Tolerance
BS 949 - 1982 part 3
Flute Type
Straight flutes
Surface Treatment
Bright
Application
For hand tapping of through or blind holes in steel, some stainless steels, cast irons and non-ferrous materials such as Aluminium & Brass.
Manufactured To
ISO 2284
Material
HSS
Pair Consists of
Taper & bottom

There are no downloads for this product.

You need to be logged in to see prices.
Code Description Diameter Type TPI Overall Length (mm) Thread Length (mm) Square Section (mm) Pack Qty Packaged In/On Price
5575-00081 BSPT TPR 1/8 TW2 Brooke 1/8" Taper 28 59 15 6.3 1 Box
You need to be logged in to see prices.
5575-00082 BSPT SEC 1/8 TW2 1/8" Second 28 59 15 6.3 1 Box
You need to be logged in to see prices.
5575-00083 BSPT BOT 1/8 TW2 Brooke 1/8" Bottom 28 59 15 6.3 1 Box
You need to be logged in to see prices.
5575-00161 BSPT TPR 1/4 TW3 Brooke 1/4" Taper 19 67 19 8 1 Box
You need to be logged in to see prices.
5575-00162 BSPT SEC 1/4 TW3 Brooke 1/4" Second 14 67 19 8 1 Box
You need to be logged in to see prices.
5575-00163 BSPT BOT 1/4 TW3 Brooke 1/4" Bottom 19 67 19 8 1 Box
You need to be logged in to see prices.
5575-00241 BSPT TPR 3/8 TW4 Brooke 3/8" Taper 19 75 21 10 1 Box
You need to be logged in to see prices.
5575-00242 BSPT SEC 3/8 TW4 Brooke 3/8" Second 19 75 21 10 1 Box
You need to be logged in to see prices.
5575-00243 BSPT BOT 3/8 TW4 Brooke 3/8" Bottom 19 75 21 10 1 Box
You need to be logged in to see prices.
5575-00321 BSPT TPR 1/2 TW5 Brooke 1/2" Taper 14 87 26 12.5 1 Box
You need to be logged in to see prices.
5575-00322 BSPT SEC 1/2 TW5 Brooke 1/2" Second 14 87 26 12.5 1 Box
You need to be logged in to see prices.
5575-00323 BSPT BOT 1/2 TW5 Brooke 1/2" Bottom 14 87 26 12.5 1 Box
You need to be logged in to see prices.
5575-00481 BSPT TPR 3/4 TW5 Brooke 3/4" Taper 14 96 28 16 1 Box
You need to be logged in to see prices.
5575-00482 BSPT SEC 3/4 TW5 Brooke 3/4" Second 14 96 28 16 1 Box
You need to be logged in to see prices.
5575-00483 BSPT BOT 3/4 TW5 Brooke 3/4" Bottom 14 96 28 16 1 Box
You need to be logged in to see prices.
5575-01001 BSPT TPR 1" TW6 Brooke 1" Taper 11 109 33 20 1 Box
You need to be logged in to see prices.
5575-01002 BSPT SEC 1" TW6 Brooke 1" Second 11 109 33 20 1 Box
You need to be logged in to see prices.
5575-01003 BSPT BOT 1 inch TW6 Brooke 1" Bottom 11 109 33 20 1 Box
