BSW Spiral Flute Machine Taps

Descriptions

Type of Thread
Whitworth thread
Tap Tolerance
Class 2 for medium fit
Flute Type
35° spiral flutes
Surface Treatment
Bright
Application
For machine tapping of blind holes in steel,stainless steels, cast irons and non-ferrous materials such as aluminium & brass.
Manufactured To
ISO 529
Material
HSSE-V

Specifications

Downloads

There are no downloads for this product.

You need to be logged in to see prices.

Code	Description	Diameter	TPI	Overall Length (mm)	Thread Length (mm)	Square Section (mm)	Pack Qty	Packaged In/On	Price
5528-0012	BSW SP.FL 3/16 Co5 ISO529 TAP Brooke	3/16"	24	58	16	4	1	Box	You need to be logged in to see prices.
5528-0016	BSW SP.FL 1/4 Co5 ISO529 TAP Brooke	1/4"	20	66	19	5	1	Box	You need to be logged in to see prices.
5528-0024	BSW SP.FL 3/8 Co5 ISO529 TAP Brooke	3/8"	16	80	24	8	1	Box	You need to be logged in to see prices.
5528-0032	BSW SP.FL 1/2 Co5 ISO529 TAP Brooke	1/2"	12	89	29	7.1	1	Box	You need to be logged in to see prices.
5528-0048	BSW SP.FL 3/4 Co5 ISO529 TAP Brooke	3/4"	10	112	37	11.2	1	Box	You need to be logged in to see prices.

You need to be logged in to see prices.
