Side & Face Cutters Staggered Tooth
Side & Face Cutters Staggered Tooth

Side & Face Cutters Staggered Tooth

Descriptions

Teeth
Staggered.
Application
Designed deep slot operations in steel and in most soft materials,these cutters have alternate right and left hand spiral teeth providing ample chip clearance for fast stock removel.
Manufactured To
Part number 2003 to BS 122
Part number 2005 to Din 885A Type N
Material
HSS

There are no downloads for this product.

You need to be logged in to see prices.
Code Description Diameter Pack Qty Bore Size Number of Teeth Width Price
2003-1001 2.1/2x1/2x1 S&F STG Side & Face Cutter 2.1/2" 1 1" 16 1/2"

POA
2003-1011 3x1/4x1 S&F STAG Side & Face Cutter 3" 1 1" 16 1/4"

POA
2003-1013 3x3/8x1 S&F STAG Side & Face Cutter 3" 1 1" 16 3/8"

POA
2003-1015 3x1/2x1 S&F STAG Side & Face Cutter 3" 1 1" 16 1/2"

POA
2003-1021 3.1/2x1/4x1 S&F STG Side & Face Cutter 3.1/2" 1 1" 18 1/4"

POA
2003-1025 3.1/2x1/2x1 S&F STG Side & Face Cutter 3.1/2" 1 1" 18 1/2"

POA
2003-1033 4x1/4x1 S&F STAG Side & Face Cutter 4" 1 1" 18 1/4"

POA
2003-1038 4x3/8x1 S&F STAG Side & Face Cutter 4" 1 1" 18 3/8"

POA
2003-1042 4x1/2x1 S&F STAG Side & Face Cutter 4" 1 1" 18 1/2"

POA
2003-1061 5x1/4x1 S&F STAG Side & Face Cutter 5" 1 1" 24 1/4"

POA
2003-1069 5x1/2x1 S&F STAG Side & Face Cutter 5" 1 1" 24 1/2"

POA
2003-1090 6x3/16x1 S&F STAG Side & Face Cutter 6" 1 1" 24 3/16"

POA
2003-1092 6x1/4x1 S&F STAG Side & Face Cutter 6" 1 1" 24 1/4"

POA
2003-1100 6x1/2x1 S&F STAG Side & Face Cutter 6" 1 1" 24 1/2"

POA
2005-1000 50x4x16 S&F STAG Side & Face Cutter 50mm 1 16mm 10 4mm

POA
2005-1001 50x5x16 S&F STAG 50mm 1 16mm 10 5mm

POA
2005-1002 50x6x16 S&F STAG 50mm 1 16mm 10 6mm

POA
2005-1003 50x8x16 S&F STAG Side & Face Cutter 50mm 1 16mm 10 8mm

POA
2005-1011 63x5x22 S&F STAG Side & Face Cutter 63mm 1 22mm 12 5mm

POA
2005-1012 63x6x22 S&F STAG Side & Face Cutter 63mm 1 22mm 12 6mm

POA
2005-1013 63x8x22 S&F STAG Side & Face Cutter 63mm 1 22mm 12 8mm

POA
2005-1020 80x5x27 S&F STAG Side & Face Cutter 80mm 1 27mm 14 5mm

POA
2005-1021 80x6x27 S&F STAG Side & Face Cutter 80mm 1 27mm 14 6mm

POA
2005-1022 80x8x27 S&F STAG 80mm 1 27mm 14 8mm

POA
2005-1101 100x8x27 S&F STAG Side & Face Cutter 100mm 1 27mm 16 8mm

POA
2005-1103 100x12x27 S&F STAG Side & Face Cutter 100mm 1 27mm 16 12mm

POA
2005-1121 125x8x32 S&F STAG Side & Face Cutter 125mm 1 32mm 16 8mm

POA
2005-1124 125x12x32 S&F STAG 125mm 1 32mm 16 12mm

POA
2005-1141 160x10x40 S&F STAG Side & Face Cutter 160mm 1 40mm 18 10mm

POA
2005-1142 160x12x40 S&F STAG Side & Face Cutter 160mm 1 40mm 18 12mm

POA
