Equal Angle Cutters

Descriptions

Teeth
Straight.Radial to centre.
Application
Used for milling vee-shaped slots,serrations and chamfers.Note a 1.0mm flat may be added to maintain integrity of the cutting point on certain angle and diameter combinations.
Manufactured To
BS 122
Material
HSS

Specifications

Downloads

There are no downloads for this product.

You need to be logged in to see prices.

Code	Description	Diameter	Pack Qty	Bore Size	Number of Teeth	Width	RH Angle	Price
2031-1001	2.3/4x5/16x1x30E EAC	2.3/4"	1	1"	28	5/16"	30?	POA
2031-1010	3x5/16x1x30E EAC	3"	1	1"	32	5/16"	30?	POA
2031-1002	2.3/4x1/2x1x45E EAC	2.3/4"	1	1"	24	1/2"	45?	POA
2031-1060	4x3/4x1x45E EAC	4"	1	1"	20	3/4"	45?	POA
2031-1003	2.3/4x1/2x1x60E EAC	2.3/4"	1	1"	20	1/2"	60?	POA
2031-1030	3x5/8x1x60E EAC	3"	1	1"	20	5/8"	60?	POA
2031-1061	4x3/4x1x60E EAC	4"	1	1"	20	3/4"	60?	POA
2031-1032	3x5/8x1x90E EAC	3"	1	1"	20	5/8"	90?	POA
2031-1041	3x3/4x1x90E EAC	3"	1	1"	18	3/4"	90?	POA
2031-1062	4x3/4x1x90E EAC	4"	1	1"	20	3/4"	90?	POA
