Morse Bi-Metal Master Cobalt Holesaws

Application
For drilling hard/soft wood, hard steel ,stainless steel, brass, bronze, cast iron, aluminium and plastic.
49mm (1-7/8") cutting depth.
Smooth cutting action.
8% cobalt M42 high speed steel cutting edge wire and tough fatigue resistant backer - Long life and faster cut
NEW Patent pending set tooth design - Better chip clearance and smooth cutting action
NEW Cap - Is able to take punishment and abuse while being lighter and therefore easier to manoeuvre than our competitors.
NEW Exterior coating   - reduced friction and give more efficient cutting performance
Heavy duty 1.3mm wall - stronger body, increased durability
NEW Side slot - Easier slug removal

Material
Bi-metal M42 high speed steel cutting edge.

Bi-metal
(BIM) is a high-carbon steel body for flexibility and break-resistance, and high-speed steel cutting edge for heat-resistance, hardness, and durability. With these holsaws been M42, they will have a even greater heat-resistance, wear-resistance, than their M3 counterparts.

Carbide Tipped & Carbide Grit Holesaws are also available please contact us Click Here.

There are no downloads for this product.

You need to be logged in to see prices.
Code Description Diameter Cutting Depth Pack Qty Packaged In/On Price
C416-0140 14.0mm 9/16 Morse HSS-Co8 Bi-Metal Holesaw 14.0mm 9/16" 49mm 1 Box
C416-0160 16.0mm 5/8 Morse HSS-Co8 Bi-Metal Holesaw 16.0mm 5/8" 49mm 1 Box
C416-0170 17.0mm 11/16 Morse HSS-Co8 Bi-Metal Holesaw 17.0mm 11/16" 49mm 1 Box
C416-0190 19.0mm 3/4 Morse HSS-Co8 Bi-Metal Holesaw 19.0mm 3/4" 49mm 1 Box
C416-0200 20.0mm 25/32 Morse HSS-Co8 Bi-Metal Holesaw 20.0mm 25/32" 49mm 1 Box
C416-0210 21.0mm 13/16 Morse HSS-Co8 Bi-Metal Holesaw 21.0mm 13/16" 49mm 1 Box
C416-0220 22.0mm 7/8 Morse HSS-Co8 Bi-Metal Holesaw 22.0mm 7/8" 49mm 1 Box
C416-0240 24.0mm 15/16 Morse HSS-Co8 Bi-Metal Holesaw 24.0mm 15/16" 49mm 1 Box
C416-0250 25.0mm 1 Morse HSS-Co8 Bi-Metal Holesaw 25.0mm 1" 49mm 1 Box
C416-0270 27.0mm 1.1/16 Morse HSS-Co8 Bi-Metal Holesaw 27.0mm 1.1/16" 49mm 1 Box
C416-0290 29.0mm 1.1/8 Morse HSS-Co8 Bi-Metal Holesaw 29.0mm 1.1/8" 49mm 1 Box
C416-0300 30.0mm 1.3/16 Morse HSS-Co8 Bi-Metal Holesaw 30.0mm 1.3/16" 49mm 1 Box
C416-0320 32.0mm 1.1/4 Morse HSS-Co8 Bi-Metal Holesaw 32.0mm 1.1/4" 49mm 1 Box
C416-0330 33.0mm 1.5/16 Morse HSS-Co8 Bi-Metal Holesaw 33.0mm 1.5/16" 49mm 1 Box
C416-0350 35.0mm 1.3/8 Morse HSS-Co8 Bi-Metal Holesaw 35.0mm 1.3/8" 49mm 1 Box
C416-0370 37.0mm (1.7/16) Morse HSS-Co8 Bi-Metal Holesaw 37.0mm 1.7/16" 49mm 1 Box
C416-0380 38.0mm (1.1/2 ) Morse HSS-Co8 Bi-Metal Holesaw 38.0mm 1.1/2" 49mm 1 Box
C416-0400 40.0mm (1.9/16) Morse HSS-Co8 Bi-Metal Holesaw 40.0mm 1.9/16" 49mm 1 Box
C416-0410 41.0mm (1.5/8 ) Morse HSS-Co8 Bi-Metal Holesaw 41.0mm 1.5/8" 49mm 1 Box
C416-0430 43.0mm (1.11/16) Morse HSS-Co8 Bi-Metal Holesaw 43.0mm 1.11/16" 49mm 1 Box
C416-0440 44.0mm (1.3/4 ) Morse HSS-Co8 Bi-Metal Holesaw 44.0mm (1.3/4" 49mm 1 Box
C416-0460 46.0mm (1.13/16) Morse HSS-Co8 Bi-Metal Holesaw 46.0mm 1.13/16" 49mm 1 Box
C416-0480 48.0mm (1.7/8 ) Morse HSS-Co8 Bi-Metal Holesaw 48.0mm 1.7/8 " 49mm 1 Box
C416-0500 50mm (1.61/64) Morse HSS-Co8 Bi-Metal Holesaw 50mm 49mm 1 Box
C416-0510 51.0mm (2 inch) Morse HSS-Co8 Bi-Metal Holesaw 51.0mm 2 inch" 49mm 1 Box
C416-0520 52.0mm (2.1/16) Morse HSS-Co8 Bi-Metal Holesaw 52.0mm 2.1/16" 49mm 1 Box
C416-0540 54.0mm (2.1/8 ) Morse HSS-Co8 Bi-Metal Holesaw 54.0mm 2.1/8" 49mm 1 Box
C416-0550 55.0mm (2.3/16) Morse HSS-Co8 Bi-Metal Holesaw 55.0mm 2.3/16" 49mm 1 Box
C416-0570 57.0mm (2.1/4 ) Morse HSS-Co8 Bi-Metal Holesaw 57.0mm 2.1/4" 49mm 1 Box
C416-0590 59.0mm (2.5/16) Morse HSS-Co8 Bi-Metal Holesaw 59.0mm 2.5/16" 49mm 1 Box
C416-0600 60.0mm (2.3/8 ) Morse HSS-Co8 Bi-Metal Holesaw 60.0mm 2.3/8" 49mm 1 Box
C416-0640 64.0mm (2.1/2 ) Morse HSS-Co8 Bi-Metal Holesaw 64.0mm 2.1/2" 49mm 1 Box
C416-0650 65.0mm (2.9/16) Morse HSS-Co8 Bi-Metal Holesaw 65.0mm 2.9/16" 49mm 1 Box
C416-0670 67.0mm (2.5/8 ) Morse HSS-Co8 Bi-Metal Holesaw 67.0mm 2.5/8" 49mm 1 Box
C416-0700 70.0mm (2.3/4 ) Morse HSS-Co8 Bi-Metal Holesaw 70.0mm 2.3/4" 49mm 1 Box
C416-0730 73.0mm (2.7/8 ) Morse HSS-Co8 Bi-Metal Holesaw 73.0mm 2.7/8" 49mm 1 Box
C416-0750 75.0mm (2.15/16) Morse HSS-Co8 Bi-Metal Holesaw 75.0mm 2.15/16" 49mm 1 Box
C416-0760 76.0mm (3 inch) Morse HSS-Co8 Bi-Metal Holesaw 76.0mm 3" 49mm 1 Box
C416-0790 79.0mm (3.1/8 ) Morse HSS-Co8 Bi-Metal Holesaw 79.0mm 3.1/8" 49mm 1 Box
C416-0830 83.0mm (3.1/4 ) Morse HSS-Co8 Bi-Metal Holesaw 83.0mm 3.1/4" 49mm 1 Box
C416-0860 86.0mm (3.3/8 ) Morse HSS-Co8 Bi-Metal Holesaw 86.0mm 3.3/8" 49mm 1 Box
C416-0890 89.0mm (3.1/2 ) Morse HSS-Co8 Bi-Metal Holesaw 89.0mm 3.1/2" 49mm 1 Box
C416-0920 92.0mm (3.5/8 ) Morse HSS-Co8 Bi-Metal Holesaw 92.0mm 3.5/8" 49mm 1 Box
C416-0950 95.0mm (3.3/4 ) Morse HSS-Co8 Bi-Metal Holesaw 95.0mm 3.3/4" 49mm 1 Box
C416-0980 98.0mm (3.7/8 ) Morse HSS-Co8 Bi-Metal Holesaw 98.0mm 3.7/8" 49mm 1 Box
C416-1020 102.0mm (4 inch) Morse HSS-Co8 Bi-Metal Holesaw 102.0mm 4" 49mm 1 Box
C416-1050 105.0mm (4.1/8 ) Morse HSS-Co8 Bi-Metal Holesaw 105.0mm 4.1/8" 49mm 1 Box
C416-1080 108.0mm (4.1/4 ) Morse HSS-Co8 Bi-Metal Holesaw 108.0mm 4.1/4" 49mm 1 Box
C416-1110 111.0mm (4.3/8 ) Morse HSS-Co8 Bi-Metal Holesaw 111.0mm 4.3/8" 49mm 1 Box
C416-1140 114.0mm (4.1/2 ) Morse HSS-Co8 Bi-Metal Holesaw 114.0mm 4.1/2" 49mm 1 Box
C416-1210 121.0mm (4.3/4 ) Morse HSS-Co8 Bi-Metal Holesaw 121.0mm 4.3/4" 49mm 1 Box
C416-1270 127.0mm (5 inch) Morse HSS-Co8 Bi-Metal Holesaw 127.0mm 5" 49mm 1 Box
C416-1400 140.0mm (5.1/2 ) Morse HSS-Co8 Bi-Metal Holesaw 140.0mm 5.1/2" 49mm 1 Box
C416-1520 152.0mm (6 inch) Morse HSS-Co8 Bi-Metal Holesaw 152.0mm 6" 49mm 1 Box
