HSS-Co5 1/4" Hex QC Drill Bits

Descriptions

Flute Type
Standard helix,right hand,ground flutes
Point Angle
135° split point with 7 cutting edge tips for superior drilling performance
Surface Treatment
Straw Finish
Shank Type
1/4"(6mm) hex quick-change shank, suitable for impact drivers (with or without impact on)
Application
Drills in steel, high tensile steel up to 1000N/mm2, stainless steel V2A/V4A, cast steel, cast iron,non-ferrous metals and hard plastics
Manufactured To
Din 338
Material
HSS-Co5

Specifications

Downloads

There are no downloads for this product.

You need to be logged in to see prices.

Code	Description	Diameter	Flute Length (mm)	Shank Type	Overall Length (mm)	Pack Qty	Packaged In/On	Price
C172-0025	2.5mm HSS-Co5 1/4" Quick-CHG Shank Impact Jobber Drill Bit	2.5mm	19	1/4"(6mm) hex QC, impact rated	62	1	Wallet	You need to be logged in to see prices.
C172-0030	3.0mm HSS-Co5 1/4" Quick-CHG Shank Impact Jobber Drill Bit	3.0mm	23	1/4"(6mm) hex QC, impact rated	65	1	Wallet	You need to be logged in to see prices.
C172-0033	3.3mm HSS-Co5 1/4" Quick-CHG Shank Impact Jobber Drill Bit	3.3mm	24	1/4"(6mm) hex QC, impact rated	67	1	Wallet	You need to be logged in to see prices.
C172-0035	3.5mm HSS-Co5 1/4" Quick-CHG Shank Impact Jobber Drill Bit	3.5mm	25	1/4"(6mm) hex QC, impact rated	69	1	Wallet	You need to be logged in to see prices.
C172-0040	4.0mm HSS-Co5 1/4" Quick-CHG Shank Impact Jobber Drill Bit	4.0mm	26	1/4"(6mm) hex QC, impact rated	71.5	1	Wallet	You need to be logged in to see prices.
C172-0042	4.2mm HSS-Co5 1/4" Quick-CHG Shank Impact Jobber Drill Bit	4.2mm	28	1/4"(6mm) hex QC, impact rated	74	1	Wallet	You need to be logged in to see prices.
C172-0045	4.5mm HSS-Co5 1/4" Quick-CHG Shank Impact Jobber Drill Bit	4.5mm	29	1/4"(6mm) hex QC, impact rated	76	1	Wallet	You need to be logged in to see prices.
C172-0050	5.0mm HSS-Co5 1/4" Quick-CHG Shank Impact Jobber Drill Bit	5.0mm	31	1/4"(6mm) hex QC, impact rated	80	1	Wallet	You need to be logged in to see prices.
C172-0055	5.5mm HSS-Co5 1/4" Quick-CHG Shank Impact Jobber Drill Bit	5.5mm	60	1/4"(6mm) hex QC, impact rated	104	1	Wallet	You need to be logged in to see prices.
C172-0060	6.0mm HSS-Co5 1/4" Quick-CHG Shank Impact Jobber Drill Bit	6.0mm	63	1/4"(6mm) hex QC, impact rated	105	1	Wallet	You need to be logged in to see prices.
C172-10SET	10Pc HSS-Co5 2.5-6.0mmx0.5mm +3.3,4.2mm 1/4" Quick-CHG IMP	10Pc set, HSS-Co5, 2.5-6.0mmx0.5mm, +3.3, 4.2mm		1/4"(6mm) hex QC, impact rated		1	Euro hanging tube	You need to be logged in to see prices.
