BSF Taps
BSF Taps
BSF Taps

BSF Taps

Descriptions

Type of Thread
British standard fine thread
Tap Tolerance
Class 2 for medium fit
Flute Type
Straight flutes
Surface Treatment
Bright
Application
For hand tapping of through or blind holes in steel, some stainless steels, cast irons and non-ferrous materials such as aluminium & brass.
Manufactured To
ISO 529
Material
HSS
Set Consists of
Taper,second,bottom

There are no downloads for this product.

You need to be logged in to see prices.
Code Description Diameter Type TPI Overall Length (mm) Thread Length (mm) Square Section (mm) Pack Qty Packaged In/On Price
5531-0016 HSS BSF SET 1/4 ISO529 TAPSET Brooke 1/4" Set(3) 26 66 19 5 1 Box
You need to be logged in to see prices.
5531-00161 HSS BSF TPR 1/4 ISO529 TAP Brooke 1/4" Taper 26 66 19 5 1 Box
You need to be logged in to see prices.
5531-00162 HSS BSF SEC 1/4 ISO529 TAP Brooke 1/4" Second 26 66 19 5 1 Box
You need to be logged in to see prices.
5531-00163 HSS BSF BOT 1/4 ISO529 TAP Brooke 1/4" Bottom 26 66 19 5 1 Box
You need to be logged in to see prices.
5531-0020 HSS BSF SET 5/16 ISO529 TAPSET Brooke 5/16" Set(3) 22 72 22 6.3 1 Box
You need to be logged in to see prices.
5531-00201 HSS BSF TPR 5/16 ISO529 TAP Brooke 5/16" Taper 22 72 22 6.3 1 Box
You need to be logged in to see prices.
5531-00202 HSS BSF SEC 5/16 ISO529 TAP Brooke 5/16" Second 22 72 22 6.3 1 Box
You need to be logged in to see prices.
5531-00203 HSS BSF BOT 5/16 ISO529 TAP Brooke 5/16" Bottom 22 72 22 6.3 1 Box
You need to be logged in to see prices.
5531-0024 HSS BSF SET 3/8 ISO529 TAPSET Brooke 3/8" Set(3) 20 80 24 8 1 Box
You need to be logged in to see prices.
5531-00241 HSS BSF TPR 3/8 ISO529 TAP Brooke 3/8" Taper 20 80 24 8 1 Box
You need to be logged in to see prices.
5531-00242 HSS BSF SEC 3/8 ISO529 TAP Brooke 3/8" Second 20 80 24 8 1 Box
You need to be logged in to see prices.
5531-00243 HSS BSF BOT 3/8 ISO529 TAP Brooke 3/8" Bottom 20 80 24 8 1 Box
You need to be logged in to see prices.
5531-0032 HSS BSF SET 1/2 ISO529 TAPSET Brooke 1/2" Set(3) 16 89 29 7.1 1 Box
You need to be logged in to see prices.
5531-00321 HSS BSF TPR 1/2 ISO529 TAP Brooke 1/2" Taper 16 89 29 7.1 1 Box
You need to be logged in to see prices.
5531-00322 HSS BSF SEC 1/2 Brooke 1/2" Second 16 89 29 7.1 1 Box
You need to be logged in to see prices.
5531-00323 HSS BSF BOT 1/2 ISO529 TAP Brooke 1/2" Bottom 16 89 29 7.1 1 Box
You need to be logged in to see prices.
5531-0040 HSS BSF SET 5/8 Brooke 5/8" Set(3) 14 102 32 10 1 Box
You need to be logged in to see prices.
5531-00401 HSS BSF TPR 5/8 ISO529 TAP Brooke 5/8" Taper 14 102 32 10 1 Box
You need to be logged in to see prices.
5531-00402 HSS BSF SEC 5/8 Brooke 5/8" Second 14 102 32 10 1 Box
You need to be logged in to see prices.
5531-00403 HSS BSF BOT 5/8 ISO529 TAP Brooke 5/8" Bottom 14 102 32 10 1 Box
You need to be logged in to see prices.
