Drill Sleeves

Application
To reduce the machine taper to suit smaller Morse Taper Shanks on tool in use.
Surface Treatment
Bright
Manufactured To
ISO 235 Din 345 BS 328 - Hardened and ground.

There are no downloads for this product.

You need to be logged in to see prices.
Code Description Morse Taper Overall Length(mm) Morse Taper Outside Morse Taper Inside Pack Qty Price
2071-1000 1-0 MT. H&G SLEEVE 1-0 MT. 85 1 0 1
2071-1002 2 Out - 1 In MT. H&G SLEEVE 2-1 MT. 92 2 1 1
2071-1003 3 Out - 1 In MT. H&G SLEEVE 3-1 MT. 99 3 1 1
2071-1004 3 Out - 2 In MT. H&G SLEEVE 3-2 MT. 112 3 2 1
2071-1005 4 Out - 1 In MT. H&G SLEEVE 4-1 MT. 124 4 1 1
2071-1006 4 Out - 2 In MT. H&G SLEEVE 4-2 MT. 124 4 2 1
2071-1007 4 Out - 3 In MT. H&G SLEEVE 4-3 MT. 140 4 3 1
2071-1008 5 Out - 1 In MT. H&G SLEEVE 5-1 MT. 156 5 1 1
2071-1009 5 Out - 2 In MT. H&G SLEEVE 5-2 MT. 156 5 2 1
2071-1010 5 Out - 3 In MT. H&G SLEEVE 5-3 MT. 156 5 3 1
2071-1011 5 Out-4 In MT. H&G SLEEVE 5-4 MT. 171 5 4 1
2071-1013 6 Out - 3 In MT. H&G SLEEVE 6-3 MT. 218 6 3 1
2071-1014 6 Out - 4 In MT. H&G SLEEVE 6-4 MT. 218 6 4 1
2071-1015 6 Out - 5 In MT. H&G SLEEVE 6-5 MT. 218 6 5 1
You need to be logged in to see prices.
