Extension Sockets

Application
For extending spindle to take larger,smaller or the same size More Taper Shank.
Surface Treatment
Bright
Manufactured To
ISO 235 Din 345 BS 328 - Hardened and ground.

There are no downloads for this product.

You need to be logged in to see prices.
Code Description Morse Taper Overall Length(mm) Morse Taper Outside Morse Taper Inside Pack Qty Price
2073-1101 1 O/S -2 IN MT. H&G EXT.SCKT 1-2 MT. 91 1 2 1
2073-1102 2 O/S -1 In MT. H&G EXT.SCKT 2-1 MT. 76 2 1 1
2073-1103 2-2 MT. H&G EXT.SCKT 2-2 MT. 91 2 2 1
2073-1104 2 O/S -3 IN MT. H&G EXT.SCKT 2-3 MT. 112 2 3 1
2073-1105 3 O/S -1 IN MT. H&G EXT.SCKT 3-1 MT. 76 3 1 1
2073-1106 3 O/S -2 IN MT. H&G EXT.SCKT 3-2 MT. 91 3 2 1
2073-1107 3 O/S -3 IN MT. H&G EXT.SCKT 3-3 MT. 112 3 3 1
2073-1108 3 O/S-4 IN MT. H&G EXT.SCKT 3-4 MT. 140 3 4 1
2073-1110 4 O/S -2 IN MT. H&G EXT.SCKT 4-2 MT. 91 4 2 1
2073-1111 4 O/S -3 IN MT. H&G EXT.SCKT 4-3 MT. 112 4 3 1
2073-1112 4 O/S -4 IN MT. H&G EXT.SCKT 4-4 MT. 140 4 4 1
2073-1113 4 O/S -5 IN MT. H&G EXT.SCKT 4-5 MT. 177 4 5 1
2073-1117 5 O/S -4 IN MT. H&G EXT.SCKT 5-4 MT. 137 5 4 1
2073-1118 5 O/S -5 IN MT. H&G EXT.SCKT 5-5 MT. 172 5 5 1
