Hand Taper Pin Reamers
Hand Taper Pin Reamers

Hand Taper Pin Reamers

Descriptions

Taper
1:50.
Shank
Straight shank with square.
Surface Treatment
Blue flutes,bright lands
Application
Reaming holes to suit standard taper pins.
Manufactured To
ISO 3465 Din 9 BS 328
Material
HSS

There are no downloads for this product.

You need to be logged in to see prices.
Code Description Diameter Flute Length(mm) Overall Length(mm) Pack Qty Packaged In/On Price
5731-0020 REAM TAPER PIN 2.0 2.0mm 48mm 68mm 1 Box
You need to be logged in to see prices.
5731-0030 REAM TAPER PIN 3.0 3.0mm 58mm 80mm 1 Box
You need to be logged in to see prices.
5731-0040 REAM TAPER PIN 4.0 4.0mm 68mm 93mm 1 Box
You need to be logged in to see prices.
5731-0050 REAM TAPER PIN 5.0 5.0mm 73mm 100mm 1 Box
You need to be logged in to see prices.
5731-0060 REAM TAPER PIN 6.0 6.0mm 105mm 135mm 1 Box
You need to be logged in to see prices.
5731-0080 REAM TAPER PIN 8.0 8.0mm 145mm 180mm 1 Box
You need to be logged in to see prices.
5731-0100 REAM TAPER PIN 10.0 10.0mm 175mm 215mm 1 Box
You need to be logged in to see prices.
5731-0120 REAM TAPER PIN12.0 12.0mm 210mm 255m 1 Box
You need to be logged in to see prices.
5731-0130 REAM TAPER PIN 13.0 13.0mm 210mm 255mm 1 Box
You need to be logged in to see prices.
5731-0140 REAM TAPER PIN 14.0 14.0mm 210mm 255mm 1 Box
You need to be logged in to see prices.
5731-0160 REAM TAPER PIN 16.0 16.0mm 230mm 280mm 1 Box
You need to be logged in to see prices.
5731-0200 REAM TAPER PIN 20.0 20.0mm 250mm 310mm 1 Box
You need to be logged in to see prices.
5732-0006 REAM TAPER PIN 3/32 3/32" 31.8mm 57.2mm 1 Box
You need to be logged in to see prices.
5732-0008 REAM TAPER PIN 1/8 1/8" 44.5mm 69.9mm 1 Box
You need to be logged in to see prices.
5732-0010 REAM TAPER PIN 5/32 5/32" 50.8mm 76.2mm 1 Box
You need to be logged in to see prices.
5732-0012 REAM TAPER PIN 3/16 3/16" 69.9mm 101.6mm 1 Box
You need to be logged in to see prices.
5732-0016 REAM TAPER PIN 1/4 1/4" 85.7mm 117.5mm 1 Box
You need to be logged in to see prices.
5732-0020 REAM TAPER PIN 5/16 5/16" 104.8mm 142.9mm 1 Box
You need to be logged in to see prices.
5732-0024 REAM TAPER PIN 3/8 3/8" 127.4mm 165.1mm 1 Box
You need to be logged in to see prices.
5732-0032 REAM TAPER PIN 1/2 1/2" 165.1mm 209.6mm 1 Box
You need to be logged in to see prices.
