HSCo8 2 flute Long Series Flatted Shank

Descriptions

Shank Type
Flatted shank.
Flute type
30° helix.
Surface Treatment
Bright.
Application
Milling keyways and slots in one cut.Designed for plunging operations.High tensile steels and other difficult materials.
Manufactured To
ISO 1641/1 Din 844
Material
HSCo8

Specifications

Downloads

There are no downloads for this product.

You need to be logged in to see prices.

Code	Description	Diameter	Flute Length (mm)	Overall Length (mm)	Shank Type & Diameter	Pack Qty	Packaged In/On	Price
5320-0040	EM 2FCo8 L 4 Flatted Shank	4mm	11mm	63mm	Flatted 6mm	1	Box	You need to be logged in to see prices.
5320-0050	EM 2FCo8 L 5 Flatted Shank	5mm	13mm	68mm	Flatted 6mm	1	Box	You need to be logged in to see prices.
5320-0060	EM 2FCo8 L 6 Flatted Shank	6mm	13mm	68mm	Flatted 6mm	1	Box	You need to be logged in to see prices.
5320-0080	EM 2FCo8 L 8 Flatted Shank	8mm	19mm	88mm	Flatted 10mm	1	Box	You need to be logged in to see prices.
5320-0100	EM 2FCo8 L 10 Flatted Shank	10mm	22mm	95mm	Flatted 10mm	1	Box	You need to be logged in to see prices.
5320-0120	EM 2FCo8 L 12 Flatted Shank	12mm	26mm	110mm	Flatted 12mm	1	Box	You need to be logged in to see prices.
5320-0140	EM 2FCo8 L 14 Flatted Shank	14mm	26mm	110mm	Flatted 12mm	1	Box	You need to be logged in to see prices.
5320-0160	EM 2FCo8 L 16 Flatted Shank	16mm	32mm	123mm	Flatted 16mm	1	Box	You need to be logged in to see prices.
5320-0200	EM 2FCo8 L 20 Flatted Shank	20mm	38mm	141mm	Flatted 20mm	1	Box	You need to be logged in to see prices.
5320-0250	EM 2FCo8 L 25 Flatted Shank	25mm	45mm	166mm	Flatted 25mm	1	Box	You need to be logged in to see prices.
