HSCo8 2 flute STD Length Flatted Shank

Descriptions

Shank Type
Flatted shank.
Flute type
30° helix.
Surface Treatment
Bright.
Application
Milling keyways and slots in one cut.Designed for plunging operations.High tensile steels and other difficult materials.
Manufactured To
ISO 1641/1 Din 327
Material
HSCo8

Specifications

Downloads

There are no downloads for this product.

You need to be logged in to see prices.

Code	Description	Diameter	Flute Length (mm)	Overall Length (mm)	Shank Type & Diameter	Pack Qty	Packaged In/On	Price
5305-0020	EM 2FCo8 2 Flatted Shank	2mm	3mm	47mm	Flatted 6mm	1	Box	You need to be logged in to see prices.
5305-0030	EM 2FCo8 3 Flatted Shank	3mm	5mm	49mm	Flatted 6mm	1	Box	You need to be logged in to see prices.
5305-0040	EM 2FCo8 4 Flatted Shank	4mm	7mm	51mm	Flatted 6mm	1	Box	You need to be logged in to see prices.
5305-0060	EM 2FCo8 6 Flatted Shank	6mm	8mm	52mm	Flatted 6mm	1	Box	You need to be logged in to see prices.
5305-0080	EM 2FCo8 8 Flatted Shank	8mm	11mm	61mm	Flatted 10mm	1	Box	You need to be logged in to see prices.
5305-0100	EM 2FCo8 10 Flatted Shank	10mm	13mm	63mm	Flatted 10mm	1	Box	You need to be logged in to see prices.
5305-0120	EM 2FCo8 12 Flatted Shank	12mm	16mm	73mm	Flatted 12mm	1	Box	You need to be logged in to see prices.
5305-0140	EM 2FCo8 14 Flatted Shank	14mm	16mm	73mm	Flatted 12mm	1	Box	You need to be logged in to see prices.
5305-0160	EM 2FCo8 16 Flatted Shank	16mm	19mm	79mm	Flatted 16mm	1	Box	You need to be logged in to see prices.
5305-0180	EM 2FCo8 18 Flatted Shank	18mm	19mm	79mm	Flatted 16mm	1	Box	You need to be logged in to see prices.
5305-0240	EM 2FCo8 24 Flatted Shank	24mm	26mm	102mm	Flatted 25mm	1	Box	You need to be logged in to see prices.
