HSCo8 STD Length Screwed Shank
HSCo8 STD Length Screwed Shank

HSCo8 STD Length Screwed Shank

Descriptions

Shank Type
Screwed parallel shank.
Flute type
30° helix.
Surface Treatment
Bright.
Application
For profile milling,high tensile steels and other diffcult materials.
Manufactured To
ISO 1641 BS 122
Material
HSCo8

There are no downloads for this product.

You need to be logged in to see prices.
Code Description Number of Flutes Diameter Flute Length (mm) Overall Length (mm) Shank Type & Diameter Pack Qty Packaged In/On Price
5344-0030 EM Co8 SS 3 Threaded Shank 4 3mm 10mm 54mm Screwed 6mm 1 Box
You need to be logged in to see prices.
5344-0040 EM Co8 SS 4 Threaded Shank 4 4mm 13mm 57mm Screwed 6mm 1 Box
You need to be logged in to see prices.
5344-0050 EM Co8 SS 5 Threaded Shank 4 5mm 16mm 61mm Screwed 6mm 1 Box
You need to be logged in to see prices.
5344-0060 EM Co8 SS 6 Threaded Shank 4 6mm 16mm 61mm Screwed 6mm 1 Box
You need to be logged in to see prices.
5344-0080 EM Co8 SS 8 Threaded Shank 4 8mm 18mm 64mm Screwed 10mm 1 Box
You need to be logged in to see prices.
5344-0100 EM Co8 SS 10 Threaded Shank 4 10mm 21mm 67mm Screwed 10mm 1 Box
You need to be logged in to see prices.
5344-0120 EM Co8 SS 12 Threaded Shank 4 12mm 24mm 70mm Screwed 12mm 1 Box
You need to be logged in to see prices.
5344-0160 EM Co8 SS 16 Threaded Shank 4 16mm 27mm 77mm Screwed 16mm 1 Box
You need to be logged in to see prices.
5344-0200 EM Co8 SS 20 Threaded Shank 4 20mm 38mm 84mm Screwed 16mm 1 Box
You need to be logged in to see prices.
5344-0300 EM Co8 SS 30 Threaded Shank 6 30mm 46mm 105mm Screwed 25mm 1 Box
You need to be logged in to see prices.
5345-0008 EM Co8 SS 1/8 Threaded Shank 4 1/8" 10mm 54mm Screwed 1/4" 1 Box
You need to be logged in to see prices.
5345-0016 EM Co8 SS 1/4 Threaded Shank 4 1/4" 16mm 60mm Screwed 1/4" 1 Box
You need to be logged in to see prices.
5345-0020 EM Co8 SS 5/16 Threaded Shank 4 5/16" 18mm 64mm Screwed 3/8" 1 Box
You need to be logged in to see prices.
5345-0024 EM Co8 SS 3/8 Threaded Shank 4 3/8" 22mm 67mm Screwed 3/8" 1 Box
You need to be logged in to see prices.
5345-0032 EM Co8 SS 1/2 Threaded Shank 4 1/2" 24mm 70mm Screwed 1/2" 1 Box
You need to be logged in to see prices.
5345-0048 EM Co8 SS 3/4 Threaded Shank 4 3/4" 38mm 83mm Screwed 5/8" 1 Box
