HSS STD Length Screwed Shank
HSS STD Length Screwed Shank

HSS STD Length Screwed Shank

Descriptions

Shank Type
Screwed parallel shank.
Flute type
30° helix.
Surface Treatment
Bright.
Application
For profile milling.
Manufactured To
ISO 1641 BS 122
Material
HSS

There are no downloads for this product.

You need to be logged in to see prices.
Code Description Number of Flutes Diameter Flute Length (mm) Overall Length (mm) Shank Type & Diameter Pack Qty Packaged In/On Price
5301-0080 EM M2 SS 8 Threaded Shank 4 8mm 18mm 64mm Screwed 10mm 1 Box
You need to be logged in to see prices.
5301-0100 EM M2 SS 10 Threaded Shank 4 10mm 21mm 67mm Screwed 10mm 1 Box
You need to be logged in to see prices.
5301-0120 EM M2 SS 12 Threaded Shank 4 12mm 24mm 70mm Screwed 12mm 1 Box
You need to be logged in to see prices.
5301-0140 EM M2 SS 14 Threaded Shank 4 14mm 29mm 73mm Screwed 12mm 1 Box
You need to be logged in to see prices.
5301-0160 EM M2 SS 16 Threaded Shank 4 16mm 27mm 77mm Screwed 16mm 1 Box
You need to be logged in to see prices.
5301-0180 EM M2 SS 18 Threaded Shank 4 18mm 35mm 80mm Screwed 16mm 1 Box
You need to be logged in to see prices.
5301-0200 EM M2 SS 20 Threaded Shank 4 20mm 38mm 84mm Screwed 16mm 1 Box
You need to be logged in to see prices.
5301-0220 EM M2 SS 22 Threaded Shank 6 22mm 38mm 95mm Screwed 25mm 1 Box
You need to be logged in to see prices.
5301-0240 EM M2 SS 24 x 25 Threaded Shnk 6 24mm 42mm 99mm Screwed 25mm 1 Box
You need to be logged in to see prices.
5301-0250 EM M2 SS 25 x 25 Threaded Shnk 6 25mm 45mm 101.5mm Screwed 25mm 1 Box
You need to be logged in to see prices.
5303-0016 EM M2 SS 1/4 Threaded Shank 4 1/4" 16mm 60mm Screwed 1/4" 1 Box
You need to be logged in to see prices.
5303-0020 EM M2 SS 5/16 Threaded Shank 4 5/16" 18mm 64mm Screwed 3/8" 1 Box
You need to be logged in to see prices.
5303-0024 EM M2 SS 3/8 Threaded Shank 4 3/8" 22mm 67mm Screwed 3/8" 1 Box
You need to be logged in to see prices.
5303-0040 EM M2 SS 5/8 Threaded Shank 4 5/8" 32mm 77mm Screwed 5/8" 1 Box
You need to be logged in to see prices.
5303-0048 EM M2 SS 3/4 Threaded Shank 4 3/4" 38mm 83mm Screwed 5/8" 1 Box
