Metric Coarse Spiral Flute Machine Taps - Blue Finish
Metric Coarse Spiral Flute Machine Taps - Blue Finish

Metric Coarse Spiral Flute Machine Taps - Blue Finish

Descriptions

Type of Thread
Metric ISO thread
Tap Tolerance
Class 2 for 6H fit
Flute Type
35° spiral flutes
Surface Treatment
Blue
Application
For machine tapping of blind holes in steel,stainless steels, cast irons and non-ferrous materials such as aluminium & brass.
Manufactured To
ISO 529
Material
HSSE-V

There are no downloads for this product.

You need to be logged in to see prices.
Code Description Diameter Pitch (mm) Overall Length (mm) Thread Length (mm) Square Section (mm) Pack Qty Packaged In/On Price
5510-1030 BLUE Co5 SP.FL M3 ISO 529 TAP Brooke 3.0mm 0.5 48 11 2.5 1 Box
You need to be logged in to see prices.
5510-1040 BLUE Co5 SP.FL M4 ISO 529 TAP Brooke 4.0mm 0.7 53 13 3.15 1 Box
You need to be logged in to see prices.
5510-1050 BLUE Co5 SP.FL M5 ISO 529 TAP Brooke 5.0mm 0.8 58 16 4 1 Box
You need to be logged in to see prices.
5510-1060 BLUE Co5 SP.FL M6 ISO 529 TAP Brooke 6.0mm 1 66 19 5 1 Box
You need to be logged in to see prices.
5510-1080 BLUE Co5 SP.FL M8 ISO 529 TAP Brooke 8.0mm 1.25 72 22 6.3 1 Box
You need to be logged in to see prices.
5510-1100 BLUE Co5 SP.FL M10 ISO 529 TAP Brooke 10.0mm 1.5 .80 24 8 1 Box
You need to be logged in to see prices.
5510-1120 BLUE Co5 SP.FL M12 ISO 529 TAP Brooke 12.0mm 1.75 89 29 7.1 1 Box
You need to be logged in to see prices.
5510-1140 BLUE Co5 SP.FL M14 ISO 529 TAP Brooke 14.0mm 2 95 30 9 1 Box
You need to be logged in to see prices.
5510-1160 BLUE Co5 SP.FL M16 ISO 529 TAP Brooke 16.0mm 2 102 32 10 1 Box
You need to be logged in to see prices.
5510-1200 BLUE Co5 SP.FL M20 ISO 529 TAP Brooke 20.0mm 2.5 112 37 11.2 1 Box
You need to be logged in to see prices.
5510-1240 BLUE Co5 SP.FL M24 ISO 529 TAP Brooke 24.0mm 3 130 45 14 1 Box
You need to be logged in to see prices.
You need to be logged in to see prices.
