Tungsten Carbide Tipped Precision Drill Bits

Descriptions

Flute Type
Right hand,ground flutes
Point Angle
118°
Surface Treatment
Bright finish
Application
Specially designed for drilling stainless steel and other difficult abrasive materials up to 1400 N/mm2, which cannot be successfully drilled by ordinary HSS jobber drills
Manufactured To
Din 8037
Tip Material
Tungsten carbide

Specifications

Downloads

There are no downloads for this product.

You need to be logged in to see prices.

Code	Description	Diameter	Overall Length(mm)	Pack Qty	Packaged In/On	Price
C140-0030	0901 3.0mm Din 8037 Carbide Tipped Precision Drill	3.0mm	50	1	Box	You need to be logged in to see prices.
C140-0035	0902 3.5mm Din 8037 Carbide Tipped Precision Drill	3.5mm	56	1	Box	You need to be logged in to see prices.
C140-0040	0903 4.0mm Din 8037 Carbide Tipped Precision Drill	4.0mm	56	1	Box	You need to be logged in to see prices.
C140-0045	0904 4.5mm Din 8037 Carbide Tipped Precision Drill	4.5mm	63	1	Box	You need to be logged in to see prices.
C140-0050	0905 5.0mm Din 8037 Carbide Tipped Precision Drill	5.0mm	63	1	Box	You need to be logged in to see prices.
C140-0055	0906 5.5mm Din 8037 Carbide Tipped Precision Drill	5.5mm	71	1	Box	You need to be logged in to see prices.
C140-0060	0907 6.0mm Din 8037 Carbide Tipped Precision Drill	6.0mm	71	1	Box	You need to be logged in to see prices.
C140-0065	0908 6.5mm Din 8037 Carbide Tipped Precision Drill	6.5mm	71	1	Box	You need to be logged in to see prices.
C140-0070	0909 7.0mm Din 8037 Carbide Tipped Precision Drill	7.0mm	80	1	Box	You need to be logged in to see prices.
C140-0075	0910 7.5mm Din 8037 Carbide Tipped Precision Drill	7.5mm	80	1	Box	You need to be logged in to see prices.
C140-0080	0911 8.0mm Din 8037 Carbide Tipped Precision Drill	8.0mm	80	1	Box	You need to be logged in to see prices.
C140-0085	0912 8.5mm Din 8037 Carbide Tipped Precision Drill	8.5mm	90	1	Box	You need to be logged in to see prices.
C140-0090	0913 9.0mm Din 8037 Carbide Tipped Precision Drill	9.0mm	90	1	Box	You need to be logged in to see prices.
C140-0100	0915 10.0mm Din 8037 Carbide Tipped Precision Drill	10.0mm	100	1	Box	You need to be logged in to see prices.
C140-0110	0917 11.0mm Din 8037 Carbide Tipped Precision Drill	11.0mm	100	1	Box	You need to be logged in to see prices.
C140-0120	0919 12.0mm Din 8037 Carbide Tipped Precision Drill	12.0mm	112	1	Box	You need to be logged in to see prices.
C140-0130	0921 13.0mm Din 8037 Carbide Tipped Precision Drill	13.0mm	112	1	Box	You need to be logged in to see prices.
C140-1008	0950 1/8 Din 803 Carbide Tipped Precision Drill	1/8 "	50	1	Box	You need to be logged in to see prices.
C140-1012	0952 3/16 Din 803 Carbide Tipped Precision Drill	3/16 "	63	1	Box	You need to be logged in to see prices.
C140-1016	0954 1/4 Din 803 Carbide Tipped Precision Drill	1/4 "	70	1	Box	You need to be logged in to see prices.
C140-1020	0956 5/16 Din 803 Carbide Tipped Precision Drill	5/16 "	79	1	Box	You need to be logged in to see prices.
C140-1024	0958 3/8 Din 803 Carbide Tipped Precision Drill	3/8 "	89	1	Box	You need to be logged in to see prices.
C140-1028	0960 7/16 Din 803 Carbide Tipped Precision Drill	7/16 "	100	1	Box	You need to be logged in to see prices.
C140-1032	0962 1/2 Din 803 Carbide Tipped Precision Drill	1/2 "	111	1	Box	You need to be logged in to see prices.
