Centre Drills

Flute Type
Right hand helix
Point Angle
118° with a 60° included countersink
Surface Treatment
Bright finish
Application
For general centreing operations on workpieces requiring addtional machining between centres
Manufactured To
Din 333A & BS328
Material
HSS

There are no downloads for this product.

You need to be logged in to see prices.
Code Description Diameter Overall Length (mm) Body Diameter Pack Qty Packaged In/On Price
C108-0010 1.0mm Point x 3.15m Body (1)Centre Drills 1.0mm 31.5 3.15mm 1 Box
C108-0016 1.6mm Point x 4.0m Body Centre Drills 1.6mm 35.5 4mm 1 Box
C108-0020 2.0mm Point x 5.0mm Body Centre Drills 2.0mm 40 5mm 1 Box
C108-0025 2.5mm Point x 6.3m Body (3)Centre Drills 2.5mm 45 6.3mm 1 Box
C108-00315 3.15mm Point x 8.0m Body (4)Centre Drills 3.15mm 50 8mm 1 Box
C108-0040 4.0mm Point x 10.0m Body Centre Drills 4.0mm 56 10mm 1 Box
C108-0050 5.0mm Point x 12.5m Body Centre Drills 5.0mm 63 12.5mm 1 Box
C108-0063 6.3mm Point x 16.0m Body (6)Centre Drills 6.3mm 71 16mm 1 Box
C108-1001 BS1 3/64 inch Point Centre Drills BS1 1.19mm (3/64") 38 (1.1/2") 3.18mm (1/8") 1 Box
C108-1002 BS2 1/16 inch Point Centre Drills BS2 1.59mm (1/16") 45 (1.3/4") 4.76mm (3/16") 1 Box
C108-1003 BS3 3/32 inch Point Centre Drills BS3 2.38mm (3/32") 51 (2") 6.35mm (1/4") 1 Box
C108-1004 BS4 1/8 inch Point Centre Drills BS4 3.18mm (1/8") 57 (2.1/4") 7.94mm (5/16") 1 Box
C108-1005 BS5 3/16 inch Point Centre Drills BS5 4.76mm (3/16") 64 (2.1/2") 11.11mm (7/16") 1 Box
C108-1006 BS6 1/4 inch Point Centre Drills BS6 6.35mm (1/4") 76 (3") 15.88mm (5/8") 1 Box
C108-1007 BS7 5/16 inch Point Centre Drills BS7 7.94mm (5/16") 86 (3.1/2") 19.05mm (3/4") 1 Box
