HSS-G Combination Drill & Tap Bits

Descriptions

Thread Type
Metric coarse
Flute Type
Spiral flutes with deburring zone edge breaker
Shank Type
1/4" quick change hex shank
Surface Treatment
Bright
Application
For unalloyed and low-alloyed steels up to 600N/mm2,malleable cast iron and non-ferrous metals.
Manufactured To
Work standard
Material
HSS

Specifications

Downloads

There are no downloads for this product.

You need to be logged in to see prices.

Code	Description	Diameter	Type	Pitch (mm)	Description & Size	Shank Type	Overall Length (mm)	Pack Qty	Packaged In/On	Price
5156-0030	M3.0x.50 HSS Combination Drill & Tap	M3	Combination Drill & Tap	0.5		1/4" Hex	52	1	Box	You need to be logged in to see prices.
5156-0040	M4.0x0.70 HSS Combination Drill & Tap	M4	Combination Drill & Tap	0.7		1/4" Hex	52	1	Box	You need to be logged in to see prices.
5156-0050	M5.0x0.80 HSS Combination Drill & Tap	M5	Combination Drill & Tap	0.8		1/4" Hex	57	1	Box	You need to be logged in to see prices.
5156-0060	M6.0x1.0 HSS Combination Drill & Tap	M6	Combination Drill & Tap	1		1/4" Hex	57	1	Box	You need to be logged in to see prices.
5156-0080	M8x1.25 HSS Combination Drill & Tap	M8	Combination Drill & Tap	1.25		1/4" Hex	79	1	Box	You need to be logged in to see prices.
5156-0100	M10x1.50 HSS Combination Drill & Tap	M10	Combination Drill & Tap	1.5		1/4" Hex	79	1	Box	You need to be logged in to see prices.
5156-0000	M3-M10 Combination Drill & Tap Set + Magnetic Bit Holder 7Pc				7PCE Comb Drill & Tap Set, M3, M4, M5, M6, M8, M10 + Magnetic Bit Holder	1/4" Hex		1	Case	You need to be logged in to see prices.
