BSF Dies
BSF Dies

BSF Dies

Descriptions

Type of Thread
British standard fine
Tolerance
Medium bolt
Surface Treatment
Bright
Application
For threading steel, some stainless steels, cast irons and non-ferrous materials such as Aluminium & Brass.
Manufactured To
BS 1127:1950
Material
HSS

There are no downloads for this product.

You need to be logged in to see prices.
Code Description Diameter Pitch (mm) Die O/D Pack Qty Packaged In/On Price
6270-0002 HSS 1/4x26TPIx13/16" BSF Die Brooke 1/4" 26 13/16" 1 Box
You need to be logged in to see prices.
6270-0022 HSS 1/4x26TPIx1" BSF Die Brooke 1/4" 26 1" 1 Box
You need to be logged in to see prices.
6270-0023 HSS 5/16x22TPIx1" BSF Die Brooke 5/16" 22 1" 1 Box
You need to be logged in to see prices.
6270-0024 HSS 3/8x20TPIx1" BSF Die Brooke 3/8" 20 1" 1 Box
You need to be logged in to see prices.
6270-0032 HSS 3/8x20TPIx1.5/16 BSF Die Brooke 3/8" 20 1.5/16" 1 Box
You need to be logged in to see prices.
6270-0033 HSS7/16x18TPIx1.5/16 BSF Die Brooke 7/16" 18 1.5/16" 1 Box
You need to be logged in to see prices.
6270-0044 HSS 1/2x16TPIx1.1/2 BSF Die Brooke 1/2" 16 1.1/2" 1 Box
You need to be logged in to see prices.
6270-0045 HSS9/16x16TPIx1.1/2 BSF Die Brooke 9/16" 16 1.1/2" 1 Box
You need to be logged in to see prices.
6270-0046 HSS 5/8x14TPIx1.1/2 BSF Die Brooke 5/8" 14 1.1/2" 1 Box
You need to be logged in to see prices.
6270-0066 HSS 3/4x12TPIx2" BSF Die Brooke 3/4" 12 2" 1 Box
You need to be logged in to see prices.
6270-0068 HSS 1"x10TPIx2" BSF Die Brooke 1" 10 2" 1 Box
You need to be logged in to see prices.
