UNC Dies
UNC Dies

UNC Dies

Descriptions

Type of Thread
Unified coarse
Tolerance
2A
Surface Treatment
Bright
Application
For threading steel, some stainless steels, cast irons and non-ferrous materials such as Aluminium & Brass.
Manufactured To
BS 1127:1950
Material
HSS

There are no downloads for this product.

You need to be logged in to see prices.
Code Description Diameter Pitch (mm) Die O/D Pack Qty Packaged In/On Price
6230-0005 HSS NO.6x32TPIx13/16 HSS UNC DIES Brooke No.6 32 13/16" 1 Box
You need to be logged in to see prices.
6230-0009 HSS 1/4 inch x20TPIx13/16 HSS UNC DIES Brooke 1/4" 20 13/16" 1 Box
You need to be logged in to see prices.
6230-0007 HSS NO10x24TPIx13/16 UNC Brooke No.10 24 1" 1 Box
You need to be logged in to see prices.
6230-0008 HSS NO12x24TPIx13/16 Brooke No.12 24 1" 1 Box
You need to be logged in to see prices.
6230-0025 HSS 1/4 x20TPIx1 inch UNC DIES Brooke 1/4" 20 1" 1 Box
You need to be logged in to see prices.
6230-0026 HSS 5/16 x18TPIx1 inch UNC DIES Brooke 5/16" 18 1" 1 Box
You need to be logged in to see prices.
6230-0027 HSS 3/8 x16TPIx1 inch UNC DIES Brooke 3/8" 16 1" 1 Box
You need to be logged in to see prices.
6230-0031 HSS 5/16x18TPx1-5/16 UNC DIES Brooke 5/16" 18 1.5/16" 1 Box
You need to be logged in to see prices.
6230-0032 HSS 3/8x16TPIx1-5/16 UNC DIES Brooke 3/8" 16 1.5/16" 1 Box
You need to be logged in to see prices.
6230-0033 HSS 7/16x14TPx1-5/16 UNC DIES Brooke 7/16" 14 1.5/16" 1 Box
You need to be logged in to see prices.
6230-0034 HSS 1/2x13TPIx1-5/16 UNC DIES Brooke 1/2" 13 1.5/16" 1 Box
You need to be logged in to see prices.
6230-0035 HSS 9/16x12TPx1-5/16 UNC DIES Brooke 9/16" 12 1.5/16" 1 Box
You need to be logged in to see prices.
6230-0042 HSS 3/8x16TPIx1.1/2 UNC DIES Brooke 3/8" 16 1.1/2" 1 Box
You need to be logged in to see prices.
6230-0043 HSS 7/16x14TPIx1.1/2 UNC DIES Brooke 7/16" 14 1.1/2" 1 Box
You need to be logged in to see prices.
6230-0044 HSS 1/2x13TPIx1.1/2 UNC DIES Brooke 1/2" 13 1.1/2" 1 Box
You need to be logged in to see prices.
6230-0046 HSS 5/8x11TPIx1.1/2 UNC DIES Brooke 5/8" 11 1.1/2" 1 Box
You need to be logged in to see prices.
6230-0047 HSS 3/4x10TPIx1.1/2 UNC DIES Brooke 3/4" 10 1.1/2" 1 Box
You need to be logged in to see prices.
6230-0066 HSS 7/8x9TPIx2 inch UNC DIES Brooke 7/8" 9 2" 1 Box
You need to be logged in to see prices.
6230-0067 HSS 1 x8TPIx2 inch UNC DIES Brooke 1" 8 2" 1 Box
You need to be logged in to see prices.
6230-0093 HSS 1.1/4x7TPIx3 inch UNC DIES Brooke 1.1/4" 7 3" 1 Box
You need to be logged in to see prices.
6230-0094 HSS 1.3/8x6TPIx3 inch UNC DIES Brooke 1.3/8" 6 3" 1 Box
You need to be logged in to see prices.
6230-0095 HSS 1.1/2x6TPIx3 inch UNC DIES Brooke 1.1/2" 6 3" 1 Box
You need to be logged in to see prices.
