Metric Fine Dies
Metric Fine Dies

Metric Fine Dies

Descriptions

Type of Thread
Metric fine
Tolerance
6g
Surface Treatment
Bright
Application
For threading steel, some stainless steels, cast irons and non-ferrous materials such as Aluminium & Brass.
Manufactured To
BS 1127:1950
Material
HSS

There are no downloads for this product.

You need to be logged in to see prices.
Code Description Diameter Pitch (mm) Die O/D Pack Qty Packaged In/On Price
6220-0007 HSS M4.0x0.50x13/16 inch METRIC FINE DIES Brooke 4.0mm 0.5 3/16" 1 Box
You need to be logged in to see prices.
6220-0010 HSS M5.0x0.50x13/16 inch METRIC FINE DIES Brooke 5.0mm 0.5 3/16" 1 Box
You need to be logged in to see prices.
6220-0013 HSS M6.0x0.75x13/16 inch METRIC FINE DIES Brooke 6.0mm 0.75 3/16" 1 Box
You need to be logged in to see prices.
6220-0020 HSS M8.0x0.75x1 inch METRIC FINE DIES Brooke 8.0mm 0.75 1" 1 Box
You need to be logged in to see prices.
6220-0021 HSS M8.0x1.00x1 inch METRIC FINE DIES Brooke 8.0mm 1 1" 1 Box
You need to be logged in to see prices.
6220-0023 HSS M10.0x0.75x1 inch METRIC FINE DIES Brooke 10.0mm 0 1" 1 Box
You need to be logged in to see prices.
6220-0024 HSS M10.0x1.00x1 inch METRIC FINE DIES Brooke 10.0mm 1 1" 1 Box
You need to be logged in to see prices.
6220-0025 HSS M10.0x1.25x1 inch METRIC FINE DIES Brooke 10.0mm 1 1" 1 Box
You need to be logged in to see prices.
6220-0033 HSS M12x1.00x1-5/16 inch METRIC FINE DIES Brooke 12.0mm 1 1.5/16" 1 Box
You need to be logged in to see prices.
6220-0034 HSS M12x1.25x1-5/16 inch METRIC FINE DIES Brooke 12.0mm 1.25 1.5/16" 1 Box
You need to be logged in to see prices.
6220-0035 HSS M12x1.50x1-5/16 inch METRIC FINE DIES Brooke 12.0mm 1.5 1.5/16" 1 Box
You need to be logged in to see prices.
6220-0036 HSS M14x1.25x1-5/16 inch METRIC FINE DIES Brooke 14.0mm 1.25 1.5/16" 1 Box
You need to be logged in to see prices.
6220-0037 HSS M14x1.50x1-5/16 inch METRIC FINE DIES Brooke 14.0mm 1.5 1.5/16" 1 Box
You need to be logged in to see prices.
6220-0040 HSS M16x1.00x1-1/2 inch METRIC FINE DIES Brooke 16.0mm 1 1.1/2" 1 Box
You need to be logged in to see prices.
6220-0041 HSS M16x1.50x1-1/2 inch METRIC FINE DIES Brooke 16.0mm 1.5 1.1/2" 1 Box
You need to be logged in to see prices.
6220-0043 HSS M18x1.50x1-1/2 inch METRIC FINE DIES Brooke 18.0mm 1.5 1.1/2" 1 Box
You need to be logged in to see prices.
6220-0045 HSS M20x1.00x1-1/2 inch METRIC FINE DIES Brooke 20.0mm 1 1.1/2" 1 Box
You need to be logged in to see prices.
6220-0061 HSS M16x1.50x2 inch METRIC FINE DIES Brooke 16.0mm 1.5 2" 1 Box
You need to be logged in to see prices.
6220-0064 HSS M20x1.50x2 inch METRIC FINE DIES Brooke 20.0mm 1.5 2" 1 Box
You need to be logged in to see prices.
6220-0066 HSS M22x1.50x2 inch METRIC FINE DIES Brooke 22.0mm 1.5 2" 1 Box
You need to be logged in to see prices.
6220-0069 HSS M24x1.50x2 inch METRIC FINE DIES Brooke 24.0mm 1.5 2" 1 Box
You need to be logged in to see prices.
6220-0071 HSS M25x1.50x2 inch METRIC FINE DIES Brooke 25.0mm 1.5 2" 1 Box
You need to be logged in to see prices.
6220-0093 HSS M30x2.00x3 inch METRIC FINE DIES Brooke 30.0mm 2 3" 1 Box
