BSW Die Nuts
BSW Die Nuts

BSW Die Nuts

Descriptions

Type of Thread
Whitworth
Tolerance
Medium
Surface Treatment
Bright
Application
For threading steel, some stainless steels, cast irons and non-ferrous materials such as Aluminium & Brass.
Manufactured To
BS 1127:1950
Material
HSS

There are no downloads for this product.

You need to be logged in to see prices.
Code Description Diameter Pitch (mm) Pack Qty Packaged In/On Across Flats Price
6262-0206 HSS 1/4x20TPIx.710 BSW DIENUTS Brooke 1/4" 20 1 Box 18.25mm
You need to be logged in to see prices.
6262-0207 HSS 5/16x18TPIx.820 BSW DIENUTS Brooke 5/16" 18 1 Box 21.0mm
You need to be logged in to see prices.
6262-0208 HSS 3/8x16TPIx.920 BSW DIENUTS Brooke 3/8" 16 1 Box 23.50mm
You need to be logged in to see prices.
6262-0209 HSS 7/16x14TPIx1.010 BSW DIENUTS Brooke 7/16" 14 1 Box 25.75mm
You need to be logged in to see prices.
6262-0210 HSS 1/2x12TPIx1.100 BSW DIENUTS Brooke 1/2" 12 1 Box 28.0mm
You need to be logged in to see prices.
6262-0212 HSS 5/8x11TPIx1.300 BSW DIENUTS Brooke 5/8" 11 1 Box 33.50mm
You need to be logged in to see prices.
6262-0214 HSS 3/4x10TPIx1.480 BSW DIENUTS Brooke 3/4" 10 1 Box 38.0mm
You need to be logged in to see prices.
6262-0216 HSS 7/8x9TPIx1.670 BSW DIENUTS Brooke 7/8" 9 1 Box 42.50mm
You need to be logged in to see prices.
6262-0218 HSS 1 inch x8TPIx2.050 BSW DIENUTS Brooke 1" 8 1 Box 52.0mm
You need to be logged in to see prices.
6262-0220 HSS 1.1/4x7TPIx2.220 BSW DIENUTS Brooke 1.1/4" 7 1 Box 57.0mm
You need to be logged in to see prices.
You need to be logged in to see prices.
