Metric Fine Die Nuts
Metric Fine Die Nuts

Metric Fine Die Nuts

Descriptions

Type of Thread
Metric fine
Tolerance
6g
Surface Treatment
Bright
Application
For threading steel, some stainless steels, cast irons and non-ferrous materials such as Aluminium & Brass.
Manufactured To
BS 1127:1950
Material
HSS

There are no downloads for this product.

You need to be logged in to see prices.
Code Description Diameter Pitch (mm) Pack Qty Packaged In/On Across Flats Price
6222-0205 HSS M5.0x0.50x0.71 inch METRIC FINE DIENUTS Brooke 5.0mm 0.5 1 Box 18.25mm
You need to be logged in to see prices.
6222-0207 HSS M6.0x0.75x0.71 inch METRIC FINE DIENUTS Brooke 6.0mm 0.75 1 Box 18.25mm
You need to be logged in to see prices.
6222-0209 HSS M8.0x0.75x0.82 inch METRIC FINE DIENUTS Brooke 8.0mm 0.75 1 Box 21.0mm
You need to be logged in to see prices.
6222-0210 HSS M8.0x1.00x0.82 inch METRIC FINE DIENUTS Brooke 8.0mm 1 1 Box 21.0mm
You need to be logged in to see prices.
6222-0211 HSS M9.0x1.00x0.92 inch METRIC FINE DIENUTS Brooke 9.0mm 1 1 Box 23.50mm
You need to be logged in to see prices.
6222-0212 HSS M10.0x0.75x0.92 inch METRIC FINE DIENUTS Brooke 10.0mm 0.75 1 Box 23.50mm
You need to be logged in to see prices.
6222-0213 HSS M10.0x1.00x0.92 inch METRIC FINE DIENUTS Brooke 10.0mm 1 1 Box 23.50mm
You need to be logged in to see prices.
6222-0214 HSS M10.0x1.25x0.92 inch METRIC FINE DIENUTS Brooke 10.0mm 1.25 1 Box 23.50mm
You need to be logged in to see prices.
6222-0215 HSS M12.0x1.00x1.10 inch METRIC FINE DIENUTS Brooke 12.0mm 1 1 Box 28.0mm
You need to be logged in to see prices.
6222-0216 HSS M12.0x1.25x1.10 inch METRIC FINE DIENUTS Brooke 12.0mm 1.25 1 Box 28.0mm
You need to be logged in to see prices.
6222-0217 HSS M12.0x1.50x1.10 inch METRIC FINE DIENUTS Brooke 12.0mm 1.5 1 Box 28.0mm
You need to be logged in to see prices.
6222-0218 HSS M14.0x1.25x1.30 inch METRIC FINE DIENUTS Brooke 14.0mm 1.25 1 Box 33.50mm
You need to be logged in to see prices.
6222-0219 HSS M14.0x1.50x1.30 inch METRIC FINE DIENUTS Brooke 14.0mm 1.5 1 Box 33.50mm
You need to be logged in to see prices.
6222-0220 HSS M16.0x1.00x1.30 inch METRIC FINE DIENUTS Brooke 16.0mm 1 1 Box 33.50mm
You need to be logged in to see prices.
6222-0221 HSS M16.0x1.50x1.30 inch METRIC FINE DIENUTS Brooke 16.0mm 1.5 1 Box 33.50mm
You need to be logged in to see prices.
6222-0223 HSS M18.0x1.50x1.48 inch METRIC FINE DIENUTS Brooke 18.0mm 1.5 1 Box 38.0mm
You need to be logged in to see prices.
6222-0225 HSS M20.0x1.00x1.48 inch METRIC FINE DIENUTS Brooke 20.0mm 1 1 Box 38.0mm
You need to be logged in to see prices.
6222-0226 HSS M20.0x1.50x1.48 inch METRIC FINE DIENUTS Brooke 20.0mm 1.5 1 Box 38.0mm
You need to be logged in to see prices.
6222-0227 HSS M20.0x2.00x1.48 inch METRIC FINE DIENUTS Brooke 20.0mm 2 1 Box 38.0mm
You need to be logged in to see prices.
6222-0228 HSS M22.0x1.50x1.67 inch METRIC FINE DIENUTS Brooke 22.0mm 1.5 1 Box 42.50mm
You need to be logged in to see prices.
6222-0230 HSS M24.0x1.00x2.05 inch METRIC FINE DIENUTS Brooke 24.0mm 1 1 Box 52.0mm
You need to be logged in to see prices.
6222-0231 HSS M24.0x1.50x2.05 inch METRIC FINE DIENUTS Brooke 24.0mm 1.5 1 Box 52.0mm
You need to be logged in to see prices.
6222-0232 HSS M24.0x2.00x2.05 inch METRIC FINE DIENUTS Brooke 24.0mm 2 1 Box 52.0mm
You need to be logged in to see prices.
6222-0233 HSS M25.0x1.50x2.05 inch METRIC FINE DIENUTS Brooke 25.0mm 1.5 - - 52.0mm
