UNC Die Nuts
UNC Die Nuts

UNC Die Nuts

Descriptions

Type of Thread
Unified coarse
Tolerance
2A
Surface Treatment
Bright
Application
For threading steel, some stainless steels, cast irons and non-ferrous materials such as Aluminium & Brass.
Manufactured To
BS 1127:1950
Material
HSS

There are no downloads for this product.

You need to be logged in to see prices.
Code Description Diameter Pitch (mm) Pack Qty Packaged In/On Across Flats Price
6232-0205 HSS NO.6x32TPIx.710 Brooke No.6 32 1 Box 18.25mm
You need to be logged in to see prices.
6232-0207 HSS NO.10x24TPIx.710 Brooke No.10 24 1 Box 18.25mm
You need to be logged in to see prices.
6232-0208 HSS NO.12x24TPIx.710 Brooke No.12 24 1 Box 18.25mm
You need to be logged in to see prices.
6232-0209 HSS 1/4x20TPIx.710 UNC DIENUTS Brooke 1/4" 20 1 Box 18.25mm
You need to be logged in to see prices.
6232-0210 HSS 5/16x18TPIx.820 inch UNC DIENUTS Brooke 5/16" 18 1 Box 21.0mm
You need to be logged in to see prices.
6232-0211 HSS 3/8x16TPIx.920 inch UNC DIENUTS Brooke 3/8" 16 1 Box 23.50mm
You need to be logged in to see prices.
6232-0212 HSS 7/16x14TPIx1.010 UNC DIENUTS Brooke 7/16" 14 1 Box 25.75mm
You need to be logged in to see prices.
6232-0213 HSS 1/2x13TPIx1.100 UNC DIENUTS Brooke 1/2" 13 1 Box 28.0mm
You need to be logged in to see prices.
6232-0215 HSS 5/8x11TPIx1.300 inch UNC DIENUTS Brooke 5/8" 11 1 Box 33.50mm
You need to be logged in to see prices.
6232-0216 HSS 3/4x10TPIx1.480 inch UNC DIENUTS Brooke 3/4" 10 1 Box 38.0mm
You need to be logged in to see prices.
6232-0217 HSS 7/8x9TPIx1.670 UNC DIENUTS Brooke 7/8" 9 1 Box 42.50mm
You need to be logged in to see prices.
6232-0218 HSS 1 inch x8TPIx2.050 UNC DIENUTS Brooke 1" 8 1 Box 52.0mm
You need to be logged in to see prices.
6232-0221 HSS 1.3/8x6TPIx2.580 UNC DIENUTS Brooke 1.3/8" 6 1 Box 66.0mm
You need to be logged in to see prices.
6232-0222 HSS 1.1/2x6TPIx2.760 Brooke 1.1/2" 6 1 Box 70.0mm
You need to be logged in to see prices.
6232-0223 HSS 1.3/4x5TPIx3.150 UNC DIENUTS Brooke 1.3/4" 5 1 Box 80.0mm
You need to be logged in to see prices.
6232-0224 HSS 2 inch x4.5TPIx3.550 UNC DIENUTS Brooke 2" 4.5 1 Box 90.0mm
