UNF Die Nuts
UNF Die Nuts

UNF Die Nuts

Descriptions

Type of Thread
Unified fine
Tolerance
2A
Surface Treatment
Bright
Application
For threading steel, some stainless steels, cast irons and non-ferrous materials such as Aluminium & Brass.
Manufactured To
BS 1127:1950
Material
HSS

There are no downloads for this product.

You need to be logged in to see prices.
Code Description Diameter Pitch (mm) Pack Qty Packaged In/On Across Flats Price
6242-0210 HSS 1/4x28TPIx.710 UNF DIENUTS Brooke 1/4" 28 1 Box 18.25mm
You need to be logged in to see prices.
6242-0211 HSS 5/16x24TPIx.820 UNF DIENUTS Brooke 5/16" 24 1 Box 21.0mm
You need to be logged in to see prices.
6242-0212 HSS 3/8x24TPIx.920 UNF DIENUTS Brooke 3/8" 24 1 Box 23.50mm
You need to be logged in to see prices.
6242-0213 HSS 7/16x20TPIx1.010 UNF DIENUTS Brooke 7/16" 20 1 Box 25.75mm
You need to be logged in to see prices.
6242-0214 HSS 1/2x20TPIx1.100 UNF DIENUTS Brooke 1/2" 20 1 Box 28.0mm
You need to be logged in to see prices.
6242-0215 HSS 9/16x18TPIx1.300 UNF DIENUTS Brooke 9/16" 18 1 Box 33.50mm
You need to be logged in to see prices.
6242-0216 HSS 5/8x18TPIx1.300 UNF DIENUTS Brooke 5/8" 18 1 Box 33.50mm
You need to be logged in to see prices.
6242-0217 HSS 3/4x16TPIx1.480 UNF DIENUTS Brooke 3/4" 16 1 Box 38.0mm
You need to be logged in to see prices.
6242-0218 HSS 7/8x14TPIx1.670 UNF DIENUTS Brooke 7/8" 14 1 Box 42.50mm
You need to be logged in to see prices.
6242-0219 HSS 1"x12TPIx2.050 UNF DIENUTS BROOKE 1" 12 1 Box 52.0mm
You need to be logged in to see prices.
6242-0221 HSS1.1/4x12TPIx2.220 UNF DIENUTS BROOKE 1.1/4" 12 1 Box 57.0mm
You need to be logged in to see prices.
6242-0223 HSS1.1/2x12TPIx2.760 UNF DIENUTS Brooke 1.1/2" 12 1 Box 70.0mm
