Centre Drills

Descriptions

Flute Type
Right hand helix
Point Angle
118° with a 60° included countersink
Surface Treatment
Bright finish
Application
For general centreing operations on workpieces requiring addtional machining between centres
Manufactured To
Din 333
Material
HSS

Specifications

Downloads

There are no downloads for this product.

You need to be logged in to see prices.

Code	Description	Diameter	Overall Length(mm)	Pack Qty	Packaged In/On	Price
5114-0001	CENTRE DRILL B.S.1	BS1	38	1	Box	You need to be logged in to see prices.
5114-0002	CENTRE DRILL B.S.2	BS2	45	1	Box	You need to be logged in to see prices.
5114-0003	CENTRE DRILL B.S.3	BS3	51	1	Box	You need to be logged in to see prices.
5114-0004	CENTRE DRILL B.S.4	BS4	57	1	Box	You need to be logged in to see prices.
5114-0005	CENTRE DRILL B.S.5	BS5	64	1	Box	You need to be logged in to see prices.
5114-0006	CENTRE DRILL B.S.6	BS6	76	1	Box	You need to be logged in to see prices.
5114-0007	CENTRE DRILL B.S.7	BS7	89	1	Box	You need to be logged in to see prices.
5114-10100	CENTRE DRILL 1.0	1.0mm	31.5	1	Box	You need to be logged in to see prices.
5114-10160	CENTRE DRILL 1.6	1.6mm	35.5	1	Box	You need to be logged in to see prices.
5114-10200	CENTRE DRILL 2.0	2.0mm	40	1	Box	You need to be logged in to see prices.
5114-10250	CENTRE DRILL 2.5	2.5mm	45	1	Box	You need to be logged in to see prices.
5114-10315	CENTRE DRILL 3.15	3.15mm	50	1	Box	You need to be logged in to see prices.
5114-10400	CENTRE DRILL 4.0	4.0mm	56	1	Box	You need to be logged in to see prices.
5114-10500	CENTRE DRILL 5.0	5.0mm	63	1	Box	You need to be logged in to see prices.
5114-10630	CENTRE DRILL 6.3	6.3mm	71	1	Box	You need to be logged in to see prices.
5114-10800	CENTRE DRILL 8.0	8.0mm	80	1	Box	You need to be logged in to see prices.
5114-11000	CENTRE DRILL 10.0	10.0mm	100	1	Box	You need to be logged in to see prices.
