Stub Drill Bits

Stub Drill Bits

Descriptions

Flute Type
Standard helix,right hand,ground flutes
Point Angle
135° split point
Surface Treatment
Blue oxide
Application
A short robust drill for drilling in steel, high tensile steel up to 1.000N/mm2, cast steel, cast iron, metals and hard plastics.
Manufactured To
Din 1897
Material
HSS

There are no downloads for this product.

You need to be logged in to see prices.
Code Description Diameter Flute Length(mm) Overall Length(mm) Pack Qty Price
5141-0010 PS Stub Std 1.0 1.0mm 6 26 10
You need to be logged in to see prices.
5141-0015 PS Stub Std 1.5 1.5mm 9 32 10
You need to be logged in to see prices.
5141-0020 PS Stub Std 2.0 2.0mm 12 38 10
You need to be logged in to see prices.
5141-0025 PS Stub Std 2.5 2.5mm 13 40 10
You need to be logged in to see prices.
5141-0030 PS Stub Std 3.0 3.0mm 16 46 10
You need to be logged in to see prices.
5141-0032 PS Stub Std 3.2 3.2mm 18 49 10
You need to be logged in to see prices.
5141-0033 PS Stub Std 3.3 3.3mm 18 49 10
You need to be logged in to see prices.
5141-0035 PS Stub Std 3.5 3.5mm 20 52 10
You need to be logged in to see prices.
5141-0040 PS Stub Std 4.0 4.0mm 22 55 10
You need to be logged in to see prices.
5141-0041 PS Stub Std 4.1 4.1mm 22 55 10
You need to be logged in to see prices.
5141-0042 PS Stub Std 4.2 4.2mm 22 55 10
You need to be logged in to see prices.
5141-0045 PS Stub Std 4.5 4.5mm 24 58 10
You need to be logged in to see prices.
5141-0048 PS Stub Std 4.8 4.8mm 26 62 10
You need to be logged in to see prices.
5141-0049 PS Stub Std 4.9 4.9mm 26 62 10
You need to be logged in to see prices.
5141-0050 PS Stub Std 5.0 5.0mm 26 62 10
You need to be logged in to see prices.
5141-0051 PS Stub Std 5.1 5.1mm 26 62 10
You need to be logged in to see prices.
5141-0052 PS Stub Std 5.2 5.2mm 26 62 10
You need to be logged in to see prices.
5141-0055 PS Stub Std 5.5 5.5mm 28 66 10
You need to be logged in to see prices.
5141-0060 PS Stub Std 6.0 6.0mm 28 66 10
You need to be logged in to see prices.
5141-0065 PS Stub Std 6.5 6.5mm 31 70 10
You need to be logged in to see prices.
5141-0068 PS Stub Std 6.8 6.8mm 34 74 10
You need to be logged in to see prices.
5141-0070 PS Stub Std 7.0 7.0mm 34 74 10
You need to be logged in to see prices.
5141-0075 PS Stub Std 7.5 7.5mm 34 74 10
You need to be logged in to see prices.
5141-0080 PS Stub Std 8.0 8.0mm 37 79 10
You need to be logged in to see prices.
5141-0085 PS Stub Std 8.5 8.5mm 37 79 10
You need to be logged in to see prices.
5141-0090 PS Stub Std 9.0 9.0mm 40 84 10
You need to be logged in to see prices.
5141-0095 PS Stub Std 9.5 9.5mm 40 84 10
You need to be logged in to see prices.
5141-0100 PS Stub Std 10.0 10.0mm 43 89 10
You need to be logged in to see prices.
5141-0102 PS Stub Std 10.2 10.2mm 43 89 5
You need to be logged in to see prices.
5141-0105 PS Stub Std 10.5 10.5mm 43 89 5
You need to be logged in to see prices.
5141-0110 PS Stub Std 11.0 11.0mm 47 95 5
You need to be logged in to see prices.
5141-0115 PS Stub Std 11.5 11.5mm 47 95 5
You need to be logged in to see prices.
5141-0120 PS Stub Std 12.0 12.0mm 51 102 5
You need to be logged in to see prices.
5141-0125 PS Stub Std 12.5 12.5mm 51 102 5
You need to be logged in to see prices.
5141-0130 PS Stub Std 13.0 13.0mm 51 102 5
You need to be logged in to see prices.
5141-1006 PS Stub Std 3/32 3/32" 14 43 10
You need to be logged in to see prices.
5141-1007 PS Stub Std 7/64 7/64" 16 46 10
You need to be logged in to see prices.
5141-1008 PS Stub Std 1/8 1/4" 18 49 10
You need to be logged in to see prices.
5141-1009 PS Stub Std 9/64 9/64" 20 52 10
You need to be logged in to see prices.
5141-1010 PS Stub Std 5/32 5/32" 22 55 10
You need to be logged in to see prices.
5141-1011 PS Stub Std 11/64 11/64" 24 58 10
You need to be logged in to see prices.
5141-1012 PS Stub Std 3/16 3/16" 26 62 10
You need to be logged in to see prices.
5141-1013 PS Stub Std 13/64 13/64" 26 62 10
You need to be logged in to see prices.
5141-1016 PS Stub Std 1/4 1/4" 31 70 10
You need to be logged in to see prices.
5141-1020 PS Stub Std 5/16 5/16" 37 79 10
You need to be logged in to see prices.
5141-1024 PS Stub Std 3/8 3/8" 43 89 10
You need to be logged in to see prices.
