HSS-Co5 Cobalt Long Series Drills
HSS-Co5 Cobalt Long Series Drills

HSS-Co5 Cobalt Long Series Drills

Descriptions

Flute Type
Parabolic flute form,right hand helix
Point Angle
135° split point
Surface Treatment
Bright
Application
For drilling deep holes in steel, high tensile steel (stainless) up to 1.400N/mm2, cast steel, cast iron,none-ferrous metals,hard plastics and resistant to heat and wear.Parabolic flute design offers wide flutes combining with a higher helix to eliminate chip ejection difficulties.
Manufactured To
Din 340
Material
HSS-Co5
PLEASE NOTE: Prices are per drill not pack Qty.

There are no downloads for this product.

You need to be logged in to see prices.
Code Description Diameter Flute Length(mm) Overall Length(mm) Pack Qty Packaged In/On Price
5109-0030 PS ADZe DIN340 3.00 TAPER LENGTH COBALT 3.0mm 66 100 10 Box
You need to be logged in to see prices.
5109-0033 PS ADZe DIN340 3.30 TAPER LENGTH COBALT 3.3mm 69 106 10 Box
You need to be logged in to see prices.
5109-0035 PS ADZe DIN340 3.50 TAPER LENGTH COBALT 3.5mm 73 112 10 Box
You need to be logged in to see prices.
5109-0040 PS ADZe DIN340 4.00 TAPER LENGTH COBALT 4.0mm 78 119 10 Box
You need to be logged in to see prices.
5109-0042 PS ADZe DIN340 4.20 TAPER LENGTH COBALT 4.2mm 78 119 10 Box
You need to be logged in to see prices.
5109-0045 PS ADZe DIN340 4.50 TAPER LENGTH COBALT 4.5mm 82 126 10 Box
You need to be logged in to see prices.
5109-0050 PS ADZe DIN340 5.00 TAPER LENGTH COBALT 5.0mm 87 132 10 Box
You need to be logged in to see prices.
5109-0060 PS ADZe DIN340 6.00 TAPER LENGTH COBALT 6.0mm 91 139 10 Box
You need to be logged in to see prices.
5109-0065 PS ADZe DIN340 6.50 TAPER LENGTH COBALT 6.5mm 97 148 10 Box
You need to be logged in to see prices.
5109-0068 PS ADZe DIN340 6.80 TAPER LENGTH COBALT 6.8mm 102 156 10 Box
You need to be logged in to see prices.
5109-0070 PS ADZe DIN340 7.00 TAPER LENGTH COBALT 7.0mm 102 156 10 Box
You need to be logged in to see prices.
5109-0075 PS ADZe DIN340 7.50 TAPER LENGTH COBALT 7.5mm 102 156 10 Box
You need to be logged in to see prices.
5109-0080 PS ADZe DIN340 8.00 TAPER LENGTH COBALT 8.0mm 109 165 10 Box
You need to be logged in to see prices.
5109-0085 PS ADZe DIN340 8.50 TAPER LENGTH COBALT 8.5mm 109 165 10 Box
You need to be logged in to see prices.
5109-0090 PS ADZe DIN340 9.00 TAPER LENGTH COBALT 9.0mm 115 175 10 Box
You need to be logged in to see prices.
5109-0095 PS ADZe DIN340 9.50 TAPER LENGTH COBALT 9.5mm 115 175 10 Box
You need to be logged in to see prices.
5109-0100 PS ADZe DIN340 10.00 TAPER LENGTH COBALT 10.0mm 121 184 10 Box
You need to be logged in to see prices.
5109-0102 PS ADZe DIN340 10.20 TAPER LENGTH COBALT 10.2mm 121 184 5 Box
You need to be logged in to see prices.
5109-0105 PS ADZe DIN340 10.50 TAPER LENGTH COBALT 10.5mm 121 184 5 Box
You need to be logged in to see prices.
5109-0110 PS ADZe DIN340 11.00 TAPER LENGTH COBALT 11.0mm 128 195 5 Box
You need to be logged in to see prices.
5109-0120 PS ADZe DIN340 12.00 TAPER LENGTH COBALT 12.0mm 134 205 5 Box
You need to be logged in to see prices.
5109-0125 PS ADZe DIN340 12.50 TAPER LENGTH COBALT 12.5mm 134 205 5 Box
You need to be logged in to see prices.
5109-0130 PS ADZe DIN340 13.00 TAPER LENGTH COBALT 13.0mm 134 205 5 Box
You need to be logged in to see prices.
5109-0140 PS ADZe DIN340 14.00 TAPER LENGTH COBALT 14.0mm 140 215 1 Box
You need to be logged in to see prices.
