Parallel Shank Chucking Reamers

Execution
10° left hand spiral.
Shank
Straight shank.
Surface Treatment
Blue flutes,bright lands
Application
For general machine reaming.
Manufactured To
ISO 521 Din 212 BS 328
Material
HSCo

There are no downloads for this product.

You need to be logged in to see prices.
Code Description Diameter Flute Length(mm) Overall Length(mm) Pack Qty Packaged In/On Price
5751-0020 REAM PS M/C CHK 2.0 2.0mm 2mm 49mm 1 Box
5751-0030 REAM PS M/C CHK 3.0 3.0mm 3mm 61mm 1 Box
5751-0040 REAM PS M/C CHK 4.0 4.0mm 4mm 75mm 1 Box
5751-0050 REAM PS M/C CHK 5.0 5.0mm 5mm 86mm 1 Box
5751-0060 REAM PS M/C CHK 6.0 6.0mm 5.6mm 93mm 1 Box
5751-0070 REAM PS M/C CHK 7.0 7.0mm 7.1mm 109mm 1 Box
5751-0080 REAM PS M/C CHK 8.0 8.0mm 8mm 117mm 1 Box
5751-0090 REAM PS M/C CHK 9.0 9.0mm 9mm 125mm 1 Box
5751-0100 REAM PS M/C CHK 10.0 10.0mm 10mm 133mm 1 Box
5751-0110 REAM PS M/C CHK 11.0 11.0mm 10mm 142mm 1 Box
5751-0120 REAM PS M/C CHK 12.0 12.0mm 10mm 151mm 1 Box
5751-0130 REAM PS M/C CHK 13.0 13.0mm 10mm 151mm 1 Box
5751-0140 REAM PS M/C CHK 14.0 14.0mm 12.5mm 160mm 1 Box
5751-0150 REAM PS M/C CHK 15.0 15.0mm 12.5mm 162mm 1 Box
5751-0160 REAM PS M/C CHK 16.0 16.0mm 12.5mm 170mm 1 Box
5751-1008 REAM PS M/C CHK 1/8 1/8" 3.2mm 65mm 1 Box
5751-1016 REAM PS M/C CHK 1/4 1/4" 6.3mm 101mm 1 Box
5751-1024 REAM PS M/C CHK 3/8 3/8" 10mm 133mm 1 Box
5751-1032 REAM PS M/C CHK 1/2 1/2" 10mm 151mm 1 Box
