Threading Taps(Metric Coarse)

Descriptions

Type of Thread
Metric ISO thread
Tap Tolerance
Class 2 for 6H fit
Flute Type
Straight flutes
Surface Treatment
Bright
Application
For hand tapping of through or blind holes in steel, some stainless steels, cast irons and non-ferrous materials such as Aluminium & Brass.
Manufactured To
ISO 529
Material
HSS
Set Consists of
Taper,second,bottom

Specifications

Downloads

There are no downloads for this product.

You need to be logged in to see prices.

Code	Description	Diameter	Type	Pitch(mm)	Overall Length(mm)	Thread length(mm)	Size range	Square section(mm)	Pack Qty	Packaged In/On	Price
5501-0030	HSS MC3.0x.50 SET TAP ISO 529 Brooke	3.0mm	Set(3)	0.5	48	11	-	2.5	1	Box	You need to be logged in to see prices.
5501-00301	HSS MC3.0x.50 TAPER TAP ISO 529 Brooke	3.0mm	Taper	0.5	48	11	-	2.5	1	Box	You need to be logged in to see prices.
5501-00302	HSS MC3.0x.50 SECOND TAP ISO 529 Brooke	3.0mm	Second	0.5	48	11	-	2.5	1	Box	You need to be logged in to see prices.
5501-00303	HSS MC3.0x.50 BOTT'G TAP ISO 529 Brooke	3.0mm	Bottom	0.5	48	11	-	2.5	1	Box	You need to be logged in to see prices.
5501-0035	HSS MC3.5x.60 SET TAP ISO 529 Brooke	3.5mm	Set(3)	0.6	50	13	-	2.8	1	Box	You need to be logged in to see prices.
5501-00351	HSS MC3.5x.60 TAPER TAP ISO 529 Brooke	3.5mm	Taper	0.6	50	13	-	2.8	1	Box	You need to be logged in to see prices.
5501-00352	HSS MC3.5x.60 SECOND TAP ISO 529 Brooke	3.5mm	Second	0.6	50	13	-	2.8	1	Box	You need to be logged in to see prices.
5501-00353	HSS MC3.5x.60 BOTT'G TAP ISO 529 Brooke	3.5mm	Bottom	0.6	50	13	-	2.8	1	Box	You need to be logged in to see prices.
5501-0040	HSS MC4.0x.70 SET TAP ISO 529 Brooke	4.0mm	Set(3)	0.7	53	13	-	3.15	1	Box	You need to be logged in to see prices.
5501-00401	HSS MC4.0x.70 TAPER TAP ISO 529 Brooke	4.0mm	Taper	0.7	53	13	-	3.15	1	Box	You need to be logged in to see prices.
5501-00402	HSS MC4.0x.70 SECOND TAP ISO 529 Brooke	4.0mm	Second	0.7	53	13	-	3.15	1	Box	You need to be logged in to see prices.
5501-00403	HSS MC4.0x.70 BOTT'G TAP ISO 529 Brooke	4.0mm	Bottom	0.7	53	13	-	3.15	1	Box	You need to be logged in to see prices.
5501-0045	HSS MC4.5x.75 SET TAP ISO 529 Brooke	4.5mm	Set(3)	0.75	53	13	-	3.55	1	Box	You need to be logged in to see prices.
5501-00451	HSS MC4.5x.75 TAPER TAP ISO 529 Brooke	4.5mm	Taper	0.75	53	13	-	3.55	1	Box	You need to be logged in to see prices.
5501-00452	HSS MC4.5x.75 SECOND Brooke	4.5mm	Second	0.75	53	13	-	3.55	1	Box	You need to be logged in to see prices.
5501-00453	HSS MC4.5x.75 BOTT'G Brooke	4.5mm	Bottom	0.75	53	13	-	3.55	1	Box	You need to be logged in to see prices.
5501-0050	HSS MC5.0x.80 SET TAP ISO 529 Brooke	5.0mm	Set(3)	0.8	58	16	-	4	1	Box	You need to be logged in to see prices.
5501-00501	HSS MC5.0x.80 TAPER TAP ISO 529 Brooke	5.0mm	Taper	0.8	58	16	-	4	1	Box	You need to be logged in to see prices.
5501-00502	HSS MC5.0x.80 SECOND TAP ISO 529 Brooke	5.0mm	Second	0.8	58	16	-	4	1	Box	You need to be logged in to see prices.
5501-00503	HSS MC5.0x.80 BOTT'G TAP ISO 529 Brooke	5.0mm	Bottom	0.8	58	16	-	4	1	Box	You need to be logged in to see prices.
5501-0060	HSS MC6.0x1.0 SET TAP ISO 529 Brooke	6.0mm	Set(3)	1	66	19	-	5	1	Box	You need to be logged in to see prices.
5501-00601	HSS MC6.0x1.0 TAPER TAP ISO 529 Brooke	6.0mm	Taper	1	66	19	-	5	1	Box	You need to be logged in to see prices.
5501-00602	HSS MC6.0x1.0 SECOND TAP ISO 529 Brooke	6.0mm	Second	1	66	19		5	1	Box	You need to be logged in to see prices.
5501-00603	HSS MC6.0x1.0 BOTT'G TAP ISO 529 Brooke	6.0mm	Bottom	1	66	19	-	5	1	Box	You need to be logged in to see prices.
5501-0080	HSS MC8.0x1.25 SET TAP ISO 529 Brooke	8.0mm	Set(3)	1.25	72	22	-	6.3	1	Box	You need to be logged in to see prices.
5501-00801	HSS MC8.0x1.25 TAPER TAP ISO 529 Brooke	8.0mm	Taper	1.25	72	22	-	6.3	1	Box	You need to be logged in to see prices.
5501-00802	HSS MC8.0x1.25 SECND TAP ISO 529 Brooke	8.0mm	Second	1.25	72	22	-	6.3	1	Box	You need to be logged in to see prices.
5501-00803	HSS MC8.0x1.25 BOT'G TAP ISO 529 Brooke	8.0mm	Bottom	1.25	72	22	-	6.3	1	Box	You need to be logged in to see prices.
5501-0100	HSS MC10.0x1.5 SET TAP ISO 529 Brooke	10.0mm	Set(3)	1.5	80	24	-	8	1	Box	You need to be logged in to see prices.
5501-01001	HSS MC10.0x1.5 TAPER TAP ISO 529 Brooke	10.0mm	Taper	1.5	80	24	-	8	1	Box	You need to be logged in to see prices.
5501-01002	HSS MC10.0x1.5 SECND TAP ISO 529 Brooke	10.0mm	Second	1.5	80	24	-	8	1	Box	You need to be logged in to see prices.
5501-01003	HSS MC10.0x1.5 BOT'G TAP ISO 529 Brooke	10.0mm	Bottom	1.5	80	24	-	8	1	Box	You need to be logged in to see prices.
5501-0120	HSS MC12.0x1.75 SET TAP ISO 529 Brooke	12.0mm	Set(3)	1.75	89	29	-	7.1	1	Box	You need to be logged in to see prices.
5501-01201	HSS MC12.0x1.75 TAPR TAP ISO 529 Brooke	12.0mm	Taper	1.75	89	29	-	7.1	1	Box	You need to be logged in to see prices.
5501-01202	HSS MC12.0x1.75 SCND TAP ISO 529 Brooke	12.0mm	Second	1.75	89	29	-	7.1	1	Box	You need to be logged in to see prices.
5501-01203	HSS MC12.0x1.75 BOTG TAP ISO 529 Brooke	12.0mm	Bottom	1.75	89	29	-	7.1	1	Box	You need to be logged in to see prices.
5501-0140	HSS MC14.0x2.0 SET TAP ISO 529 Brooke	14.0mm	Set(3)	2	95	30	-	9	1	Box	You need to be logged in to see prices.
5501-01401	HSS MC14.0x2.0 TAPER TAP ISO 529 Brooke	14.0mm	Taper	2	95	30	-	9	1	Box	You need to be logged in to see prices.
5501-01402	HSS MC14.0x2.0 SECND TAP ISO 529 Brooke	14.0mm	Second	2	95	30	-	9	1	Box	You need to be logged in to see prices.
5501-01403	HSS MC14.0x2.0 BOT'G TAP ISO 529 Brooke	14.0mm	Bottom	2	95	30	-	9	1	Box	You need to be logged in to see prices.
5501-0160	HSS MC16.0x2.0 SET TAP ISO 529 Brooke	16.0mm	Set(3)	2	102	32	-	10	1	Box	You need to be logged in to see prices.
5501-01601	HSS MC16.0x2.0 TAPER TAP ISO 529 Brooke	16.0mm	Taper	2	102	32	-	10	1	Box	You need to be logged in to see prices.
5501-01602	HSS MC16.0x2.0 SECND TAP ISO 529 Brooke	16.0mm	Second	2	102	32	-	10	1	Box	You need to be logged in to see prices.
5501-01603	HSS MC16.0x2.0 BOT'G TAP ISO 529 Brooke	16.0mm	Bottom	2	102	32	-	10	1	Box	You need to be logged in to see prices.
5501-0180	HSS MC18.0x2.5 SET TAP ISO 529 Brooke	18.0mm	Set(3)	2.5	112	37	-	11.2	1	Box	You need to be logged in to see prices.
5501-01801	HSS MC18.0x2.5 TAPER TAP ISO 529 Brooke	18.0mm	Taper	2.5	112	37	-	11.2	1	Box	You need to be logged in to see prices.
5501-01802	HSS MC18.0x2.5 SECND TAP ISO 529 Brooke	18.0mm	Second	2.5	112	37	-	11.2	1	Box	You need to be logged in to see prices.
5501-01803	HSS MC18.0x2.5 BOT'G TAP ISO 529 Brooke	18.0mm	Bottom	2.5	112	37	-	11.2	1	Box	You need to be logged in to see prices.
5501-0200	HSS MC20.0x2.5 SET TAP ISO 529 Brooke	20.0mm	Set(3)	2.5	112	37	-	11.2	1	Box	You need to be logged in to see prices.
5501-02001	HSS MC20.0x2.5 TAPER TAP ISO 529 Brooke	20.0mm	Taper	2.5	112	37	-	11.2	1	Box	You need to be logged in to see prices.
5501-02002	HSS MC20.0x2.5 SECND TAP ISO 529 Brooke	20.0mm	Second	2.5	112	37	-	11.2	1	Box	You need to be logged in to see prices.
5501-02003	HSS MC20.0x2.5 BOT'G TAP ISO 529 Brooke	20.0mm	Bottom	2.5	112	37	-	11.2	1	Box	You need to be logged in to see prices.
5501-0220	HSS MC22.0x2.5 SET TAP ISO 529 Brooke	22.0mm	Set(3)	2.5	118	38	-	12.5	1	Box	You need to be logged in to see prices.
5501-02201	HSS MC22.0x2.5 TAPER TAP ISO 529 Brooke	22.0mm	Taper	2.5	118	38	-	12.5	1	Box	You need to be logged in to see prices.
5501-02202	HSS MC22.0x2.5 SECND TAP ISO 529 Brooke	22.0mm	Second	2.5	118	38	-	12.5	1	Box	You need to be logged in to see prices.
5501-02203	HSS MC22.0x2.5 BOT'G TAP ISO 529 Brooke	22.0mm	Bottom	2.5	118	38	-	12.5	1	Box	You need to be logged in to see prices.
5501-0240	HSS MC24.0x3.0 SET TAP ISO 529 Brooke	24.0mm	Set(3)	3	130	45	-	14	1	Box	You need to be logged in to see prices.
5501-02401	HSS MC24.0x3.0 TAPER TAP ISO 529 Brooke	24.0mm	Taper	3	130	45	-	14	1	Box	You need to be logged in to see prices.
5501-02402	HSS MC24.0x3.0 SECND TAP ISO 529 Brooke	24.0mm	Second	3	130	45	-	14	1	Box	You need to be logged in to see prices.
5501-02403	HSS MC24.0x3.0 BOT'G TAP ISO 529 Brooke	24.0mm	Bottom	3	130	45	-	14	1	Box	You need to be logged in to see prices.
C655-0015	TW/5-32" T Type Tap Wrench 1/16" to 5/32", M1 to M4	-	-	-	-	-	1/16"-5/32",M1-M4	-	1	Euro hanger	You need to be logged in to see prices.
C655-0016	TW/1-4" T Type Tap Wrench 5/32" to 1/4", M4 to M8	-	-	-	-	-	5/32"-1/4",M4-M8	-	1	Euro hanger	You need to be logged in to see prices.
C655-0017	TW/1-2" T Type Tap Wrench 1/4" to 1/2", M6 to M12	-	-	-	-	-	1/4"-1/2",M6-M12	-	1	Euro hanger	You need to be logged in to see prices.
C655-0023	TWR/5-64 to 1-4 Tap Wrench Ratchet type M2 to M6	-	-	-	-	-	5/32"-1/4",M2-M6	-	1	Euro hanger	You need to be logged in to see prices.
C655-0022	TWR/1-4 to 1-2 Tap Wrench Rachet type M6 to M12	-	-	-	-	-	1/4"-1/2",M6-M12	-	1	Euro hanger	You need to be logged in to see prices.
