UNF Taps

Descriptions

Type of Thread
Unified fine thread
Tap Tolerance
Class 2 for 2B fit
Flute Type
Straight flutes
Surface Treatment
Bright
Application
For hand tapping of through or blind holes in steel, some stainless steels, cast irons and non-ferrous materials such as Aluminium & Brass.
Manufactured To
ISO 529
Material
HSS
Set Consists of
Taper,second,bottom

Specifications

Downloads

There are no downloads for this product.

You need to be logged in to see prices.

Code	Description	Diameter	Type	TPI	Overall Length (mm)	Thread Length (mm)	Square Section (mm)	Pack Qty	Packaged In/On	Price
5551-0010	HSS No10x32 UNF SET TAP ISO 529 Brooke	No.10	Set(3)	32	58	16	4	1	Box	You need to be logged in to see prices.
5551-00101	HSS No10x32 UNF T'PR TAP ISO 529 Brooke	No.10	Taper	32	58	16	4	1	Box	You need to be logged in to see prices.
5551-00102	HSS No10x32 UNF SCND TAP ISO 529 Brooke	No.10	Second	32	58	16	4	1	Box	You need to be logged in to see prices.
5551-00103	HSS No10x32 UNF BOTG TAP ISO 529 Brooke	No.10	Bottom	32	58	16	4	1	Box	You need to be logged in to see prices.
5551-0016	HSS UNF SET 1/4 ISO529 TAPSET Brooke	1/4"	Set(3)	28	66	19	5	1	Box	You need to be logged in to see prices.
5551-00161	HSS UNF TPR 1/4 ISO529 TAP Brooke	1/4"	Taper	28	66	19	5	1	Box	You need to be logged in to see prices.
5551-00162	HSS UNF SEC 1/4 ISO529 TAP Brooke	1/4"	Second	28	66	19	5	1	Box	You need to be logged in to see prices.
5551-00163	HSS UNF BOT 1/4 ISO529 TAP Brooke	1/4"	Bottom	28	66	19	5	1	Box	You need to be logged in to see prices.
5551-0020	HSS UNF SET 5/16 ISO529 TAPSET Brooke	5/16"	Set(3)	24	69	19	6.3	1	Box	You need to be logged in to see prices.
5551-00201	HSS UNF TPR 5/16 ISO529 TAP Brooke	5/16"	Taper	24	69	19	6.3	1	Box	You need to be logged in to see prices.
5551-00202	HSS UNF SEC 5/16 ISO529 TAP Brooke	5/16"	Second	24	69	19	6.3	1	Box	You need to be logged in to see prices.
5551-00203	HSS UNF BOT 5/16 ISO529 TAP Brooke	5/16"	Bottom	24	69	19	6.3	1	Box	You need to be logged in to see prices.
5551-0024	HSS UNF SET 3/8 ISO529 TAPSET Brooke	3/8"	Set(3)	24	76	20	8	1	Box	You need to be logged in to see prices.
5551-00241	HSS UNF TPR 3/8 ISO529 TAP Brooke	3/8"	Taper	24	76	20	8	1	Box	You need to be logged in to see prices.
5551-00242	HSS UNF SEC 3/8 ISO529 TAP Brooke	3/8"	Second	24	76	20	8	1	Box	You need to be logged in to see prices.
5551-00243	HSS UNF BOT 3/8 ISO529 TAP Brooke	3/8"	Bottom	24	76	20	8	1	Box	You need to be logged in to see prices.
5551-0028	HSS UNF SET 7/16 ISO529 TAPSET Brooke	7/16"	Set(3)	20	82	22	6.3	1	Box	You need to be logged in to see prices.
5551-00281	HSS UNF TPR 7/16 ISO529 TAP Brooke	7/16"	Taper	20	82	22	6.3	1	Box	You need to be logged in to see prices.
5551-00282	HSS UNF SEC 7/16 ISO529 TAP Brooke	7/16"	Second	20	82	22	6.3	1	Box	You need to be logged in to see prices.
5551-00283	HSS UNF BOT 7/16 ISO529 TAP Brooke	7/16"	Bottom	20	82	22	6.3	1	Box	You need to be logged in to see prices.
5551-0032	HSS UNF SET 1/2 ISO529 TAPSET Brooke	1/2"	Set(3)	20	84	24	7.1	1	Box	You need to be logged in to see prices.
5551-00321	HSS UNF TPR 1/2 ISO529 TAP Brooke	1/2"	Taper	20	84	24	7.1	1	Box	You need to be logged in to see prices.
5551-00322	HSS UNF SEC 1/2 ISO529 TAP Brooke	1/2"	Second	20	84	24	7.1	1	Box	You need to be logged in to see prices.
5551-00323	HSS UNF BOT 1/2 ISO529 TAP Brooke	1/2"	Bottom	20	84	24	7.1	1	Box	You need to be logged in to see prices.
5551-0036	HSS UNF SET 9/16 ISO529 TAPSET Brooke	9/16"	Set(3)	18	90	25	9	1	Box	You need to be logged in to see prices.
5551-00361	HSS UNF TPR 9/16 ISO529 TAP Brooke	9/16"	Taper	18	90	25	9	1	Box	You need to be logged in to see prices.
5551-00362	HSS UNF SEC 9/16 ISO529 TAP Brooke	9/16"	Second	18	90	25	9	1	Box	You need to be logged in to see prices.
5551-00363	HSS UNF BOT 9/16 ISO529 TAP Brooke	9/16"	Bottom	18	90	25	9	1	Box	You need to be logged in to see prices.
5551-0040	HSS UNF SET 5/8 ISO529 TAPSET Brooke	5/8"	Set(3)	18	95	25	10	1	Box	You need to be logged in to see prices.
5551-00401	HSS UNF TPR 5/8 ISO529 TAP Brooke	5/8"	Taper	18	95	25	10	1	Box	You need to be logged in to see prices.
5551-00402	HSS UNF SEC 5/8 ISO529 TAP Brooke	5/8"	Second	18	95	25	10	1	Box	You need to be logged in to see prices.
5551-00403	HSS UNF BOT 5/8 ISO529 TAP Brooke	5/8"	Bottom	18	95	25	10	1	Box	You need to be logged in to see prices.
5551-0048	HSS UNF SET 3/4 ISO529 TAPSET Brooke	3/4"	Set(3)	16	104	29	11.2	1	Box	You need to be logged in to see prices.
5551-00481	HSS UNF TPR 3/4 ISO529 TAP Brooke	3/4"	Taper	16	104	29	11.2	1	Box	You need to be logged in to see prices.
5551-00482	HSS UNF SEC 3/4 ISO529 TAP Brooke	3/4"	Second	16	104	29	11.2	1	Box	You need to be logged in to see prices.
5551-00483	HSS UNF BOT 3/4 ISO529 TAP Brooke	3/4"	Bottom	16	104	29	11.2	1	Box	You need to be logged in to see prices.
5551-0056	HSS UNF SET 7/8 ISO529 TAPSET Brooke	7/8"	Set(3)	14	113	33	12.5	1	Box	You need to be logged in to see prices.
5551-00561	HSS UNF TPR 7/8 ISO529 TAP Brooke	7/8"	Taper	14	113	33	12.5	1	Box	You need to be logged in to see prices.
5551-00562	HSS UNF SEC 7/8 ISO529 TAP Brooke	7/8"	Second	14	113	33	12.5	1	Box	You need to be logged in to see prices.
5551-00563	HSS UNF BOT 7/8 ISO529 TAP Brooke	7/8"	Bottom	14	113	33	12.5	1	Box	You need to be logged in to see prices.
5551-0100	HSS UNF SET 1 inch ISO529 TAPSET Brooke	1"	Set(3)	12	120	35	14	1	Box	You need to be logged in to see prices.
5551-01001	HSS UNF TPR 1" Brooke	1"	Taper	12	120	35	14	1	Box	You need to be logged in to see prices.
5551-01002	HSS UNF SEC 1 inch ISO529 TAP Brooke	1"	Second	12	120	35	14	1	Box	You need to be logged in to see prices.
5551-01003	HSS UNF BOT 1 inch ISO529 TAP Brooke	1"	Bottom	12	120	35	14	1	Box	You need to be logged in to see prices.
