Metric Coarse Taps

Descriptions

Type of Thread
Metric ISO thread
Tap Tolerance
Class 2 for 6H fit
Flute Type
Straight flutes
Surface Treatment
Bright
Application
For hand tapping of through or blind holes in steel,stainless steels, cast irons and non-ferrous materials such as aluminium & brass.
Manufactured To
ISO 529
Material
HSS-E
Set Consists of
Taper,second,bottom

Specifications

Downloads

There are no downloads for this product.

You need to be logged in to see prices.

Code	Description	Diameter	Type	Pitch (mm)	Overall Length (mm)	Thread Length (mm)	Square Section (mm)	Pack Qty	Packaged In/On	Price
5502-0030	HSS-E MC3.0x.50 SET TAP ISO 529 Brooke	3.0mm	Set(3)	0.5	48	11	2.5	1	Box	You need to be logged in to see prices.
5502-00301	HSS-E MC3.0x.50 TAPER TAP ISO 529 Brooke	3.0mm	Taper	0.5	48	11	2.5	1	Box	You need to be logged in to see prices.
5502-00302	HSS-E MC3.0x.50 SECOND TAP ISO 529 Brooke	3.0mm	Second	0.5	48	11	2.5	1	Box	You need to be logged in to see prices.
5502-00303	HSS-E MC3.0x.50 BOTT'G TAP ISO 529 Brooke	3.0mm	Bottom	0.5	48	11	2.5	1	box	You need to be logged in to see prices.
5502-0040	HSS-E MC4.0x.70 SET TAP ISO 529 Brooke	4.0mm	Set(3)	0.7	53	13	3.15	1	Box	You need to be logged in to see prices.
5502-00401	HSS-E MC4.0x.70 TAPER TAP ISO 529 Brooke	4.0mm	Taper	0.7	53	13	3.15	1	Box	You need to be logged in to see prices.
5502-00402	HSS-E MC4.0x.70 SECOND TAP ISO 529 Brooke	4.0mm	Second	0.7	53	13	3.15	1	Box	You need to be logged in to see prices.
5502-00403	HSS-E MC4.0x.70 BOTT'G TAP ISO 529 Brooke	4.0mm	Bottom	0.7	53	13	3.15	1	Box	You need to be logged in to see prices.
5502-0050	HSS-E MC5.0x.80 SET TAP ISO 529 Brooke	5.0mm	Set(3)	0.8	58	16	4	1	Box	You need to be logged in to see prices.
5502-00501	HSS-E MC5.0x.80 TAPER TAP ISO 529 Brooke	5.0mm	Taper	0.8	58	16	4	1	Box	You need to be logged in to see prices.
5502-00502	HSS-E MC5.0x.80 SECOND TAP ISO 529 Brooke	5.0mm	Second	0.8	58	16	4	1	Box	You need to be logged in to see prices.
5502-00503	HSS-E MC5.0x.80 BOTT'G TAP ISO 529 Brooke	5.0mm	Bottom	0.8	58	16	4	1	Box	You need to be logged in to see prices.
5502-0060	HSS-E MC6.0x1.0 SET TAP ISO 529 Brooke	6.0mm	Set(3)	1	66	19	5	1	Box	You need to be logged in to see prices.
5502-00601	HSS-E MC6.0x1.0 TAPER TAP ISO 529 Brooke	6.0mm	Taper	1	66	19	5	1	Box	You need to be logged in to see prices.
5502-00602	HSS-E MC6.0x1.0 SECOND TAP ISO 529 Brooke	6.0mm	Second	1	66	19	5	1	Box	You need to be logged in to see prices.
5502-00603	HSS-E MC6.0x1.0 BOTT'G TAP ISO 529 Brooke	6.0mm	Bottom	1	66	19	5	1	Box	You need to be logged in to see prices.
5502-0080	HSS-E MC8.0x1.25 SET TAP ISO 529 Brooke	8.0mm	Set(3)	1.25	72	22	6.3	1	Box	You need to be logged in to see prices.
5502-00801	HSS-E MC8.0x1.25 TAPER TAP ISO 529 Brooke	8.0mm	Taper	1.25	72	22	6.3	1	Box	You need to be logged in to see prices.
5502-00802	HSS-E MC8.0x1.25 SECND TAP ISO 529 Brooke	8.0mm	Second	1.25	72	22	6.3	1	Box	You need to be logged in to see prices.
5502-00803	HSS-E MC8.0x1.25 BOT'G TAP ISO 529 Brooke	8.0mm	Bottom	1.25	72	22	6.3	1	Box	You need to be logged in to see prices.
5502-0100	HSS-E MC10.0x1.5 SET TAP ISO 529 Brooke	10.0mm	Set(3)	1.5	80	24	8	1	Box	You need to be logged in to see prices.
5502-01001	HSS-E MC10.0x1.5 TAPER TAP ISO 529 Brooke	10.0mm	Taper	1.5	80	24	8	1	Box	You need to be logged in to see prices.
5502-01002	HSS-E MC10.0x1.5 SECND TAP ISO 529 Brooke	10.0mm	Second	1.5	80	24	8	1	Box	You need to be logged in to see prices.
5502-01003	HSS-E MC10.0x1.5 BOT'G TAP ISO 529 Brooke	10.0mm	Bottom	1.5	80	24	8	1	Box	You need to be logged in to see prices.
5502-0120	HSS-E MC12.0x1.75 SET TAP ISO 529 Brooke	12.0mm	Set(3)	1.75	89	29	7.1	1	Box	You need to be logged in to see prices.
5502-01201	HSS-E MC12.0x1.75 TAPR TAP ISO 529 Brooke	12.0mm	Taper	1.75	89	29	7.1	1	Box	You need to be logged in to see prices.
5502-01202	HSS-E MC12.0x1.75 SCND TAP ISO 529 Brooke	12.0mm	Second	1.75	89	29	7.1	1	Box	You need to be logged in to see prices.
5502-01203	HSS-E MC12.0x1.75 BOTG TAP ISO 529 Brooke	12.0mm	Bottom	1.75	89	29	7.1	1	Box	You need to be logged in to see prices.
5502-0140	HSS-E MC14.0x2.0 SET TAP ISO 529 Brooke	14.0mm	Set(3)	2	95	30	9	1	Box	You need to be logged in to see prices.
5502-01401	HSS-E MC14.0x2.0 TAPER TAP ISO 529 Brooke	14.0mm	Taper	2	95	30	9	1	Box	You need to be logged in to see prices.
5502-01402	HSS-E MC14.0x2.0 SECND TAP ISO 529 Brooke	14.0mm	Second	2	95	30	9	1	Box	You need to be logged in to see prices.
5502-01403	HSS-E MC14.0x2.0 BOT'G TAP ISO 529 Brooke	14.0mm	Bottom	2	95	30	9	1	Box	You need to be logged in to see prices.
5502-0160	HSS-E MC16.0x2.0 SET TAP ISO 529 Brooke	16.0mm	Set(3)	2	102	32	10	1	Box	You need to be logged in to see prices.
5502-01601	HSS-E MC16.0x2.0 TAPER TAP ISO 529 Brooke	16.0mm	Taper	2	102	32	10	1	Box	You need to be logged in to see prices.
5502-01602	HSS-E MC16.0x2.0 SECND TAP ISO 529 Brooke	16.0mm	Second	2	102	32	10	1	Box	You need to be logged in to see prices.
5502-01603	HSS-E MC16.0x2.0 BOT'G TAP ISO 529 Brooke	16.0mm	Bottom	2	102	32	10	1	Box	You need to be logged in to see prices.
5502-0180	HSS-E MC18.0x2.5 SET TAP ISO 529 Brooke	18.0mm	set(3)	2.5	112	37	11.2	1	Box	You need to be logged in to see prices.
5502-01801	HSS-E MC18.0x2.5 TAPER TAP ISO 529 Brooke	18.0mm	Taper	2.5	112	37	11.2	1	Box	You need to be logged in to see prices.
5502-01802	HSS-E MC18.0x2.5 SECND TAP ISO 529 Brooke	18.0mm	Second	2.5	112	37	11.2	1	Box	You need to be logged in to see prices.
5502-01803	HSS-E MC18.0x2.5 BOT'G TAP ISO 529 Brooke	18.0mm	Bottom	2.5	112	37	11.2	1	Box	You need to be logged in to see prices.
5502-0200	HSS-E MC20.0x2.5 SET TAP ISO 529 Brooke	20.0mm	Set(3)	2.5	112	37	11.2	1	Box	You need to be logged in to see prices.
5502-02001	HSS-E MC20.0x2.5 TAPER TAP ISO 529 Brooke	20.0mm	Taper	2.5	112	37	11.2	1	Box	You need to be logged in to see prices.
5502-02002	HSS-E MC20.0x2.5 SECND TAP ISO 529 Brooke	20.0mm	Second	2.5	112	37	11.2	1	Box	You need to be logged in to see prices.
5502-02003	HSS-E MC20.0x2.5 BOT'G TAP ISO 529 Brooke	20.0mm	Bottom	2.5	112	37	11.2	1	Box	You need to be logged in to see prices.
5502-0240	HSS-E MC24.0x3.0 SET TAP ISO 529 Brooke	24.0mm	Set(3)	3	130	45	14	1	Box	You need to be logged in to see prices.
5502-02401	HSS-E MC24.0x3.0 TAPER TAP ISO 529 Brooke	24.0mm	Taper	3	130	45	14	1	Box	You need to be logged in to see prices.
5502-02402	HSS-E MC24.0x3.0 SECND TAP ISO 529 Brooke	24.0mm	Second	3	130	45	14	1	Box	You need to be logged in to see prices.
5502-02403	HSS-E MC24.0x3.0 BOT'G TAP ISO 529 Brooke	24.0mm	Bottom	3	130	45	14	1	Box	You need to be logged in to see prices.
5502-0300	HSS-E MC30.0x3.5 SET TAP ISO 529 Brooke	30.0mm	Set(3)	3.5	138	48	16	1	Box	You need to be logged in to see prices.
5502-03001	HSS-E MC30.0x3.5 TAPER TAP ISO 529 Brooke	30.0mm	Taper	3.5	138	48	16	1	Box	You need to be logged in to see prices.
5502-03002	HSS-E MC30.0x3.5 SECND TAP ISO 529 Brooke	30.0mm	Second	3.5	138	48	16	1	Box	You need to be logged in to see prices.
5502-03003	HSS-E MC30.0x3.5 BOT'G TAP ISO 529 Brooke	30.0mm	Bottom	3.5	138	48	16	1	Box	You need to be logged in to see prices.
