HSS Blacksmith Drill Bits (1/2" Reduced Shank)

Descriptions

Flute Type
Standard helix,right hand,milled flutes
Point Angle
118°
Shank
1/2"(12.7mm)
Surface Treatment
Blue oxide
Application
Drills in steel, high tensile steel up to 900N/mm2, cast steel, cast iron, non-ferrous metals and hard plastics.
Manufactured To
BS 328
Material
HSS

There are no downloads for this product.

You need to be logged in to see prices.
Code Description Diameter Flute Length (mm) Overall Length (mm) Pack Qty Packaged In/On Price
C103-0130 13.0mm Blacksmith Drill HSS 1/2" Parallel Shank 13.0mm 80 152 1 Box
You need to be logged in to see prices.
C103-0135 13.5mm Blacksmith Drill HSS 1/2" Parallel Shank 13.5mm 80 152 1 Box
You need to be logged in to see prices.
C103-0140 14.0mm Blacksmith Drill HSS 1/2" Parallel Shank 14.0mm 80 152 1 Box
You need to be logged in to see prices.
C103-0145 14.5mm Blacksmith Drill HSS 1/2" Parallel Shank 14.5mm 80 152 1 Box
You need to be logged in to see prices.
C103-0150 15.0mm Blacksmith Drill HSS 1/2" Parallel Shank 15.0mm 80 152 1 Box
You need to be logged in to see prices.
C103-0155 15.5mm Blacksmith Drill HSS 1/2" Parallel Shank 15.5mm 80 152 1 Box
You need to be logged in to see prices.
C103-0160 16.0mm Blacksmith Drill HSS 1/2" Parallel Shank 16.0mm 80 152 1 Box
You need to be logged in to see prices.
C103-0165 16.5mm Blacksmith Drill HSS 1/2" Parallel Shank 16.5mm 80 152 1 Box
You need to be logged in to see prices.
C103-0170 17.0mm Blacksmith Drill HSS 1/2" Parallel Shank 17.0mm 80 152 1 Box
You need to be logged in to see prices.
C103-0175 17.5mm Blacksmith Drill HSS 1/2" Parallel Shank 17.5mm 80 152 1 Box
You need to be logged in to see prices.
C103-0180 18.0mm Blacksmith Drill HSS 1/2" Parallel Shank 18.0mm 80 152 1 Box
You need to be logged in to see prices.
C103-0185 18.5mm Blacksmith Drill HSS 1/2" Parallel Shank 18.5mm 80 152 1 Box
You need to be logged in to see prices.
C103-0190 19.0mm Blacksmith Drill HSS 1/2" Parallel Shank 19.0mm 80 152 1 Box
You need to be logged in to see prices.
C103-0195 19.5mm Blacksmith Drill HSS 1/2" Parallel Shank 19.5mm 76 152 1 Box
You need to be logged in to see prices.
C103-0200 20.0mm Blacksmith Drill HSS 1/2" Parallel Shank 20.0mm 76 152 1 Box
You need to be logged in to see prices.
C103-0210 21.0mm Blacksmith Drill HSS 1/2" Parallel Shank 21.0mm 76 152 1 Box
You need to be logged in to see prices.
C103-0220 22.0mm Blacksmith Drill HSS 1/2" Parallel Shank 22.0mm 76 152 1 Box
You need to be logged in to see prices.
C103-0230 23.0mm Blacksmith Drill HSS 1/2" Parallel Shank 23.0mm 76 152 1 Box
You need to be logged in to see prices.
C103-0240 24.0mm Blacksmith Drill HSS 1/2" Parallel Shank 24.0mm 76 152 1 Box
You need to be logged in to see prices.
C103-0250 25.0mm Blacksmith Drill HSS 1/2" Parallel Shank 25.0mm 76 152 1 Box
You need to be logged in to see prices.
C103-1999 Metric 5pc Blacksmith Drill HSS 1/2" Parallel Shank 14.5, 16.0, 19.0, 22.0, 25.0mm - 5Pc Set 80 152 1 Red roller wallet
You need to be logged in to see prices.
C103-1034 17/32" Blacksmith Drill HSS 1/2" Parallel Shank 17/32 " 80 152 1 Box
You need to be logged in to see prices.
C103-1036 9/16" Blacksmith Drill HSS 1/2" Parallel Shank 9/16 " 80 152 1 Box
You need to be logged in to see prices.
C103-1038 19/32" Blacksmith Drill HSS 1/2" Parallel Shank 19/32 " 80 152 1 Box
You need to be logged in to see prices.
C103-1040 5/8" Blacksmith Drill HSS 1/2" Parallel Shank 5/8 " 80 152 1 Box
You need to be logged in to see prices.
C103-1044 11/16" Blacksmith Drill HSS 1/2" Parallel Shank 11/16 " 80 152 1 Box
You need to be logged in to see prices.
C103-1048 3/4" Blacksmith Drill HSS 1/2" Parallel Shank 3/4 " 76 152 1 Box
You need to be logged in to see prices.
C103-1050 25/32" Blacksmith Drill HSS 1/2" Parallel Shank 25/32 " 76 152 1 Box
You need to be logged in to see prices.
C103-1052 13/16" Blacksmith Drill HSS 1/2" Parallel Shank 13/16 " 76 152 1 Box
You need to be logged in to see prices.
C103-1056 7/8" Blacksmith Drill HSS 1/2" Parallel Shank 7/8 " 76 152 1 Box
You need to be logged in to see prices.
C103-1058 29/32" Blacksmith Drill HSS 1/2" Parallel Shank 29/32 " 76 152 1 Box
You need to be logged in to see prices.
C103-1060 15/16" Blacksmith Drill HSS 1/2" Parallel Shank 15/16 " 76 152 1 Box
You need to be logged in to see prices.
C103-1100 1" Blacksmith Drill HSS 1/2" Parallel Shank 1 " 76 152 1 Box
You need to be logged in to see prices.
C103-1108 1.1/8" Blacksmith Drill HSS 1/2" Parallel Shank 1.1/8 " 76 152 1 Box
You need to be logged in to see prices.
C103-1116 1.1/4" Blacksmith Drill HSS 1/2" Parallel Shank 1.1/4 " 76 152 1 Box
