HSS-G Long Series Drill Bits Walleted
HSS-G Long Series Drill Bits Walleted

HSS-G Long Series Drill Bits Walleted

Descriptions

Flute Type
Standard helix,right hand,ground flutes
Point Angle
135° split point
Surface Treatment
Blue oxide
Application
Drills in steel, high tensile steel up to 900N/mm2, cast steel, cast iron, non-ferrous metals and hard plastics.
Manufactured To
Din 340
Material
HSS

There are no downloads for this product.

You need to be logged in to see prices.
Code Description Diameter Flute Length (mm) Overall Length (mm) Pack Qty Packaged In/On Price
C106-0015W 1.50mm Long Series Ground Flute Walleted 1.50mm 45 70 1 Wallet
You need to be logged in to see prices.
C106-0020W 2.00mm Long Series Ground Flute Walleted 2.00mm 56 85 1 Wallet
You need to be logged in to see prices.
C106-0025W 2.50mm Long Series Ground Flute Walleted 2.50mm 62 95 1 Wallet
You need to be logged in to see prices.
C106-0030W 3.00mm Long Series Ground Flute Walleted 3.00mm 66 100 1 Wallet
You need to be logged in to see prices.
C106-0032W 3.20mm Long Series Ground Flute Walleted 3.20mm 69 106 1 Wallet
You need to be logged in to see prices.
C106-0035W 3.50mm Long Series Ground Flute Walleted 3.50mm 73 112 1 Wallet
You need to be logged in to see prices.
C106-0040W 4.00mm Long Series Ground Flute Walleted 4.00mm 78 119 1 Wallet
You need to be logged in to see prices.
C106-0042W 4.20mm Long Series Ground Flute Walleted 4.20mm 78 119 1 Wallet
You need to be logged in to see prices.
C106-0045W 4.50mm Long Series Ground Flute Walleted 4.50mm 82 126 1 Wallet
You need to be logged in to see prices.
C106-0048W 4.80mm Long Series Ground Flute Walleted 4.80mm 87 126 1 Wallet
You need to be logged in to see prices.
C106-0050W 5.00mm Long Series Ground Flute Walleted 5.00mm 87 132 1 Wallet
You need to be logged in to see prices.
C106-0055W 5.50mm Long Series Ground Flute Walleted 5.50mm 91 139 1 Wallet
You need to be logged in to see prices.
C106-0060W 6.00mm Long Series Ground Flute Walleted 6.00mm 91 139 1 Wallet
You need to be logged in to see prices.
C106-0065W 6.50mm Long Series Ground Flute Walleted 6.50mm 97 148 1 Wallet
You need to be logged in to see prices.
C106-0068W 6.80mm Long Series Ground Flute Walleted 6.80mm 102 156 1 Wallet
You need to be logged in to see prices.
C106-0070W 7.00mm Long Series Ground Flute Walleted 7.00mm 102 156 1 Wallet
You need to be logged in to see prices.
C106-0075W 7.50mm Long Series Ground Flute Walleted 7.50mm 102 156 1 Wallet
You need to be logged in to see prices.
C106-0080W 8.00mm Long Series Ground Flute Walleted 8.00mm 109 165 1 Wallet
You need to be logged in to see prices.
C106-0085W 8.50mm Long Series Ground Flute Walleted 8.50mm 109 165 1 Wallet
You need to be logged in to see prices.
C106-0090W 9.00mm Long Series Ground Flute Walleted 9.00mm 115 175 1 Wallet
You need to be logged in to see prices.
C106-0095W 9.50mm Long Series Ground Flute Walleted 9.50mm 115 175 1 Wallet
You need to be logged in to see prices.
C106-0100W 10.00mm Long Series Ground Flute Walleted 10.00mm 121 184 1 Wallet
You need to be logged in to see prices.
C106-0105W 10.50mm Long Series Ground Flute Walleted 10.50mm 121 184 1 Wallet
You need to be logged in to see prices.
C106-0110W 11.00mm Long Series Ground Flute Walleted 11.00mm 128 195 1 Wallet
You need to be logged in to see prices.
C106-0115W 11.50mm Long Series Ground Flute Walleted 11.50mm 128 195 1 Wallet
You need to be logged in to see prices.
C106-0120W 12.00mm Long Series Ground Flute Walleted 12.00mm 134 205 1 Wallet
You need to be logged in to see prices.
C106-0125W 12.50mm Long Series Ground Flute Walleted 12.50mm 134 205 1 Wallet
You need to be logged in to see prices.
C106-0130W 13.00mm Long Series Ground Flute Walleted 13.00mm 134 205 1 Wallet
You need to be logged in to see prices.
C106-0140W 14.00mm Long Series Ground Flute Walleted 14.00mm 140 214 1 Wallet
